036-21121-002 Rev. A (0602)
Unitary Products Group 3
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
3
EER
TOTAL SENS.
1 PH 10 SEER AC WITH N1AH / G2FD
H1RA018S06 N1AHB0806 2,5,8,10 17 G2FD024S17 650 19.0 14.1 10.50 - 9.80
H1RA024S06
N1AHB0806 2,5,8,10 17 G2FD024S17 800 24.4 18.1 10.50 - 9.55
N1AHB0806 2,5,8,10 17 G2FD030S17 850 25.0 18.5 10.60 - 9.65
H2RA030S06
N1AHB1206 5,8,10,15,19 17 G2FD030S17 1000 29.0 21.5 10.30 - 9.45
N1AHB1206 5,8,10,15,19 17 G2FD036S17 1000 30.0 22.2 10.50 - 9.65
H2RA036S06
N1AHB1206 5,8,10,15,19 17 G2FD036S17 1200 33.8 25.0 10.00 - 9.20
N1AHB1206 5,8,10,15,19 17 G2FD046S17 1200 34.4 25.5 10.15 - 9.30
H1RA042S06
N1AHC1606 5,8,10,15,20 21 G2FD042S21 1400 39.5 29.2 10.00 - 9.00
N1AHC1606 5,8,10,15,20 21 G2FD048S21 1450 41.0 30.3 10.10 - 9.15
H1RA048S06
N1AHC1606 5,8,10,15,20 21 G2FD048S21 1600 46.0 34.0 10.10 - 9.50
N1AHD2006 8,10,15,20,25,30 24 G2FD060S24 1600 47.0 34.8 10.40 - 9.70
H3RA060S06 N1AHD2006 8,10,15,20,25,30 24 G2FD060S24 1800 56.0 40.2 10.50 - 9.35
3 PH 10 SEER AC WITH N1AH / G2FD
H1RA036 S(25,46)
N1AHB1246 10,15 21 G2FD036S17 1200 33.8 25.0 10.00 - 9.20
N1AHB1246 10,15 21 G2FD042S21 1400 40.0 30.1 10.00 9.05
H1RA042S(25,46)
N1AHC1646 10,15 21 G2FD042S21 1400 39.5 29.2 10.00 - 9.00
N1AHC1646 10,15 24 G2FD048S21 1450 41.0 30.3 10.10 - 9.15
H1RA048S(25,46)
N1AHC1646 10,15 21 G2FD048S21 1600 46.0 34.0 10.10 - 9.50
N1AHD2046 10,15,29 24 G2FD048S24 1600 24.6 34.0 10.10 - 9.50
N1AHD2046 10,15,29 24 G2FD048S24 1600 46.0 34.0 10.10 - 9.50
H1RA060S(25,46)
N1AHD2046 10,15,29 24 G2FD060S24 1750 58.5 39.8 10.00 - 10.25
1 PH 10 SEER AC / F2RP / RC / FC
4
,
5
H1RA018S06
F2RC/F2FC024 5,8,10 18 - 650 17.4 12.9 10.00 - 9.00
F2RP/F2FP018 2,5,8 18 - 650 17.4 12.3 10.00 - 9.00
F2RP/F2FP024 5,8,10 18 - 650 17.4 12.9 10.00 - 9.00
H1RA024S06
F2RP/F2FP024 5,8,10 18 - 800 23.4 17.3 10.00 - 9.00
F2RP/F2FP030 5,8,10,15 18 - 800 23.6 17.5 10.00 - 9.10
H2RA030S06
F2RP/F2FP030 5,8,10,15 18 - 1000 28.4 21.0 10.00 - 9.50
F2RP/F2FP036 5,8,10,15,19 21 - 1000 28.0 20.0 10.00 - 9.00
H2RA036S06
F2RC/F2FC036 5,8,10,15 21 - 1200 33.6 21.5 10.00 - 9.10
F2RP/F2FP036 5,8,10,15,19 21 - 1200 34.4 25.2 10.20 - 9.30
F2RP/F2FP042 5,8,10,15 21 - 1200 34.4 25.2 10.15 - 9.20
H1RA042S06
F2RP/F2FP042 5,8,10,15 21 - 1400 39.5 28.9 10.00 - 9.00
F2FP048 5,8,10,15,20,25 24 - 1400 40.5 30.0 10.00 - 9.20
H1RA048S06
F2FP048 5,8,10,15,20,25 24 - 1600 45.5 33.7 10.00 - 9.15
F2FP060 5,8,10,15,20,25 24 - 1600 46.5 34.4 10.00 - 9.70
H3RA060S06 F2FP060 5,8,10,15,20,25 24 - 1800 56.0 41.0 10.00 - 9.15
3 PH 10 seer AC with F2RP / FP
H1RA036 S(25,46)
F2RC/F2FC036 5,8,10,15 21 - 1200 33.6 25.2 10.00 - 9.10
H1RA042S(25,46)
F2RP/F2FP042 5,8,10,15 21 - 1400 39.0 29.2 10.00 - 9.00
F2FP048 5,8,10,15,20,25 24 - 1400 40.5 30.4 10.00 - 9.00
H1RA048S(25,46)
F2FP048 5,8,10,15,20,25 24 - 1600 45.5 33.7 10.00 - 9.15
H1RA060S(25,46)
F2FP060 5,8,10,15,20,25 24 - 1750 58.5 39.8 10.00 - 9.80
3 PH 10 seer AC WITH K4EV
6
H1RA076S25,46 K4EV090 10,16,26,36 22 -- 2600 73.5 -- -- -- 10.00
H1RA090S25,46 K4EV090 10,16,26,36 22 -- 3280
53.8/
89.0
-- -- --
9.63/
9.30
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1 G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2 Single phase units require single phase 2HK heaters. Three phase units require three phase 2HK heaters.
3 TXV = Use 1TV700 Series Kit.
4 To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC
. models. All ratings remain the same.
5 FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D (Blower on Delay) standard.
6 H*BA-(T,W)090 is field convertible to two stage operation. Its IPLV = 11.2.
— = Not Applicable.
