036-21121-002 Rev. A (0602)
12 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
1 Phase
3 Phase
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RA036S06, H1RA036S(25,46)
INDOOR COIL MODEL NO. G1FA036S17,21
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1150 1250 1350
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75
T.C. 38.3 36.1 34.4 37.9 36.3 34.6 38.0 36.4 34.9
S.C. 24.0 23.7 24.0 24.1 24.5 24.7 24.7 25.3 25.2
K.W 3.19 3.14 3.09 3.23 3.20 3.14 3.26 3.23 3.18
85
T.C. 36.9 34.6 32.2 36.9 34.9 32.6 37.0 35.2 33.0
S.C. 24.2 23.7 22.9 24.7 24.6 23.9 25.3 25.5 24.8
K.W 3.45 3.39 3.30 3.50 3.44 3.36 3.53 3.49 3.40
95
T.C. 35.5 33.2 30.0 35.8 33.6 30.4 36.0 34.0 31.0
S.C. 24.3 23.6 21.9 25.4 24.9 23.6 26.0 25.6 24.4
K.W 3.71 3.63 3.52 3.76 3.69 3.58 3.80 3.75 3.62
105
T.C. 33.2 30.4 26.7 33.4 30.8 27.2 33.6 31.3 27.7
S.C. 23.7 22.5 20.7 24.5 23.6 21.9 25.4 24.6 23.0
K.W 3.97 3.84 3.71 4.02 3.91 3.77 4.06 3.96 3.81
115
T.C. 31.0 27.6 23.5 31.1 28.2 24.2 31.3 28.5 24.4
S.C. 23.1 21.3 19.6 23.9 22.6 20.7 24.8 23.7 21.6
K.W 4.22 4.06 3.90 4.29 4.13 3.94 4.33 4.18 4.00
125
T.C. 28.7 24.8 20.2 28.9 25.6 21.1 29.0 25.7 21.0
S.C. 22.5 20.2 18.4 23.2 21.6 19.6 24.2 22.7 20.2
K.W 4.47 4.28 4.09 4.56 4.35 4.11 4.60 4.40 4.19
NOTE:
ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM
Air Handler Coil
T.C. S.C. KW
N1AHB1206 G2FD036S17 1.01 1.00 1.00
N1AHB1206 G2FD046S17 1.02 1.02 1.00
F2RC/F2FC036 1.00 0.86 1.00
F2RP/F2FP036 1.02 1.01 1.00
F2RP/F2FP042 1.02 1.01 1.01
G1FA036S14 1.00 1.00 1.00
G1FA048S17 1.04 1.04 1.01
G1FA048S21,24 1.07 1.07 1.04
G1HD036 1.02 1.02 1.05
G2FD046S17 1.02 1.02 1.00
G1HD048 1.04 1.04 1.05
G1NA036S17J 1.02 1.02 1.01
G1NA036S21C 1.02 1.02 1.00
G1UA036S14 1.00 1.00 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S17 1.04 1.04 1.01
G1UA048S21,24 1.07 1.07 1.04
G2FD035S14 0.99 0.99 0.99
G2FD036S17 1.01 1.00 1.00
G2FD036S21 1.01 1.00 1.00
G2FD042S21 1.02 1.02 1.00
MDD42CSD 1.02 1.02 1.00
Air Handler Coil
T.C. S.C. KW
N1AHB1246 G2FD036S17 1.00 1.00 0.98
N1AHB1246 G2FD046S21 1.02 1.02 1.00
F2RC/F2FC036 1.00 0.86 1.00
G1FA048S21,24 1.07 1.07 1.04
G1NA036S17J 1.02 1.02 1.01
G1NA036S21C 1.02 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S21,24 1.07 1.07 1.04
G2FD036S17 1.01 1.00 1.00
G2FD036S21 1.01 1.00 1.00
