York H*RA036 THRU 090 Air Conditioner User Manual



036-21121-002 Rev. A (0602)
2 Unitary Products Group
1.Rated in accordance with ARI Standard 110, utilization range “A”.
2.Dual element fuses or HACR circuit breaker.
3.
All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4.
The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in length multiplied by the per foot valve.
Physical and Electrical Data - 1 Phase
MODEL
H1RA018S06 H1RA024S06 H2RA030S06 H2RA036S06 H1RA042S06 H1RA048S06 H3RA060S06
Unit Supply Voltage 208/230 – 1 – 60
Normal Voltage Range
1
187 to 252
Minimum Circuit Ampacity 12.5 15.6 17.5 21.5 26.1 30.1 37.3
Max. Overcurrent Device Amps
2
20 25 30 35 40 45 60
Compressor Type
3
Recip Recip Recip Recip Recip Recip
Scroll
B
Compressor Amps
Rated Load 9.6 12.1 13.6 16.1 19.8 23 28.8
Locked Rotor 54 57 73 82 97 110 160
Crankcase Heater No No No No No No No
Fan Motor Amps Rated Load 0.5 0.5 0.5 1.4 1.4 1.3 1.3
Fan Diameter Inches 18 18 18 18 18 22 22
Fan Motor
Rated HP 1/12 1/12 1/12 1/4 1/4 1/4 1/4
Nominal RPM 1,100 1,100 1,100 1,100 1,100 850 850
Nominal CFM 1,850 1,850 1,900 2,750 2,750 3,250 3,300
Coil
Face Area Sq. Ft. 8.00 8.00 9.15 9.15 12.58 15.72 15.72
Rows Deep 1111111
Fin / Inches 14 14 18 18 18 18 22
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 5/8 5/8 3/4 3/4 3/4 7/8 7/8
Unit Charge (Lbs. - Oz.)
4
3 - 6 3 - 11 3 - 14 3 - 15 5 - 4 7 - 5 6 - 2
Charge Per Foot, Oz.
4
0.66 0.66 0.68 0.68 0.68 0.70 .070
Operating Weight Lbs. 118 123 135 137 161 176 188
Physical and Electrical Data - 3 Phase
MODEL
H1RA
036S25
H1RA
042S25
H1RA
048S25
H1RA
060S25
H1RA
076S25
H1RA
090S25
H1RA
036S25
H1RA
042S46
H1RA
048S46
H1RA
060S46
H1RA
076S46
H1RA
090S46
Unit Supply Voltage
208/230 – 3 – 60
460 - 3 - 60
Normal Voltage Range
1
187 to 252 432 to 504
Minimum Circuit Ampacity 15.0 17.4 17.3 21.3 25.8 37.7 8.0 8.4 8.3 10.8 13.0 18.1
Max. Overcurrent Device Amps
2
25 30 30 35 40 50 15 15 15 15 20 25
Compressor Type
3
Recip Recip Recip
Scroll
B
Scroll
B
Dual Recip Recip Recip
Scroll
B
Scroll
B
Dual
Compressor Amps
Rated Load 10.9 12.8 11.7 16.0 18.9 29.4 5.8 6.1 6.1 8.0 9.5 14.0
Locked Rotor 78 78 78 125 146 260 40 39 39 67 73 128
Crankcase Heater No No No No No Yes No No No No No Yes
Fan Motor Amps Rated Load 1.4 1.4 1.3 1.3 2.2 4.6 .8 .8 .7 .8 1.2 2.3
Fan Diameter Inches 18 18 22 22 24 24 18 18 22 22 24 24
Fan Motor
Rated HP 1/4 1/4 1/4 1/4 1/3 3/4 1/4 1/4 1/5 1/4 1/3 3/4
Nominal RPM 1,100 1,100 850 850 1100 1100 1,100 1,100 850 850 1100 1100
Nominal CFM 2,750 2,750 3,250 3,450 4000 5000 2,750 2,750 3,250 3,450 4000 5000
Coil
Face Area Sq. Ft. 9.15 12.58 15.72 23.58 18.0 22.5 9.15 12.58 15.72 23.58 18.0 22.5
Rows Deep 111122111122
Fin / Inches 18 18 18 18 16 16 18 18 18 18 16 16
Liquid Line OD 3/8 3/8 3/8 3/8 1/2 1/2 3/8 3/8 3/8 3/8 1/2 1/2
Vapor Line OD 3/4 3/4 7/8 7/8 1-1/8 1-1/8 3/4 3/4 7/8 7/8 1-1/8 1-1/8
Unit Charge (Lbs. - Oz.)
4
3 - 15 5 - 4 7 - 5 9 - 7 12-3 15-3 3 - 15 5 - 4 7 - 5 9 - 7 12-3 15-3
Charge Per Foot, Oz.
4
.68 .68 .70 .70 1.26 1.26 .68 .68 .70 .70 1.26 1.26
Operating Weight Lbs. 170 176 206 228 219 368 170 176 206 228 219 368
