Unitary Products Group 15
TABLE 2: PHYSICAL DATA
Component
Models
90 120 150
Evaporator
Blower
Blower, Centrifugal (Dia. X Wd. In.) 15 x 15 15 x 15 15 x 15
Motor, Standard (HP) 1-1/2 2 3
Motor, Optional (HP) 2 3 5
Evaporator Coil
Rows 3 4 4
Fins per Inch 15 15 15
Height (in.) 324040
Face Area (ft.2) 10.6 13.2 13.2
Reheat Coil
Rows 2 2 2
Fins per Inch 13 13 13
Height (in.) 283636
Face Area (ft.2) 7.8 10 10
Condenser Fan
Quantity 2 2 4
Propeller Dia. (in., each) 24 24 24
Motor (HP, each) 1/3 3/4 1/3
CFM, Nominal (each) 3400 4400 3500
Condenser Coil
Number of Coils 2 2 4
Rows (each) 1 2 2
Fins per Inch 20 20 15
Height (in., each) 44 44 36
Face Area (ft.2 each) 14.5 14.5 11.9
Refrigerant
Charge
System 1 (lb./oz.) 8/0 12/12 22/8
System 2 (lb./oz.) 6/6 10/2 21/4
Compressors
Quantity 2 2 2
Type Recip. Recip. Scroll
Air Filters
Size (Wd. X Ht. X Thickness in.) 25 x 20 x 2 25 x 20 x 2 25 x 20 x 2
Quantity 4 4 4
