34 Unitary Products Group
MODEL
TONNAGE
VOLTAGE
COMPRESSORS
OD FAN
MOTOR
FLA
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
FLA
ELECTRIC HEATER
MODEL NO.
HEATER
KW
HEATER
AMPS
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX. FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
DJ060
208-1-60 25.0 150.0 2.3 7.6 10.0
None -- -- 51.2 70
2CE04510506 4.0 19.2 51.2 70
2CE04510706 5.6 26.9 55.7 70
2CE04511006 8.0 38.5 70.1 80
2CE04511506 11.9 57.2 93.5 100
2CE04512006 15.9 76.4 117.6 125
2CE04513006 22.2 106.7 155.4 175
230-1-60 25.0 150.0 2.3 7.6 10.0
None -- -- 51.2 70
2CE04510506 5.3 22.1 51.2 70
2CE04510706 7.5 31.3 61.1 70
2CE04511006 10.6 44.2 77.2 80
2CE04511506 15.9 66.3 104.8 110
2CE04512006 21.2 88.3 132.4 150
2CE04513006 29.6 123.3 176.2 200
208-3-60 17.3 123.0 2.3 5.2 10.0
None -- -- 39.1 50
2CE04510525
2
4.0 11.1 39.1 50
2CE04510725
2
5.6 15.5 39.1 50
2CE04511025 8.0 22.2 46.8 50
2CE04511525 11.9 33.0 60.3 70
2CE04512025 15.9 44.1 74.2 80
2CE04513025 22.2 61.6 96.0 100
230-3-60 17.3 123.0 2.3 5.2 10.0
None -- -- 39.1 50
2CE04510525
2
5.3 12.7 39.1 50
2CE04510725
2
7.5 18.0 41.6 50
2CE04511025 10.6 25.5 50.9 60
2CE04511525 15.9 38.2 66.8 70
2CE04512025 21.2 51.0 82.7 90
2CE04513025 29.6 71.2 108.0 110
460-3-60 8.4 70.0 1.3 2.6 5.0
None -- -- 19.4 25
2CE04510746
2
6.8 8.2 19.7 25
2CE04511046
2
10.1 12.1 24.7 25
2CE04511546
2
13.6 16.4 29.9 30
2CE04512046
2
19.5 23.5 38.8 40
2CE04513046
2
28.8 34.6 52.8 60
575-3-60 7.0 53.0 1.3 2.0 4.0
None -- -- 15.8 20
2CE04511058 10.6 10.2 20.2 25
2CE04511558 15.9 15.3 26.6 30
2CE04512058 21.2 20.4 33.0 35
2CE04513058 30.4 29.3 44.1 45
1. HACR Type per NEC.
2. These electric heaters do not include a fuse box. If a fuse box is required to meet a local code (i.e. Chicago), the fuse block
accessories 2FB04700825 and 2FB0470086 are available for field installation.
TABLE 29: ELECTRICAL DATA - DJ036, 048 & 060 BELT DRIVE WITH POWERED CONVENIENCE OUTLET (CONT)
