262260-YTG-E-1008
14 Johnson Controls Unitary Products
TABLE 6: DH 240 COOLING CAPACITIES (20 TON)
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
75°F 85°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
90 85 80 75 70 65 90 85 80 75 70 65
6000
77 277.0 19.1 159.2 130.7 102.2 - - - 262.0 20.5 153.7 125.2 96.7 - - -
72 263.0 18.6 196.1 167.6 139.1 110.6 - - 249.0 20.1 190.4 161.8 133.3 104.8 - -
67 249.0 18.0 233.0 204.5 176.0 147.5 119.0 - 236.0 19.6 227.0 198.5 170.0 141.5 113.0 -
62 240.6 17.9 240.6 240.6 215.3 186.8 158.3 129.8 228.6 19.4 228.6 228.6 204.2 175.7 147.1 118.6
57 237.8 17.7 237.8 237.8 213.7 185.2 156.7 128.1 226.7 19.1 226.7 226.7 203.3 174.8 146.3 117.8
7000
77 287.0 17.9 189.9 145.8 112.1 - - - 272.0 19.4 187.6 140.0 106.3 - - -
72 272.5 17.4 219.9 186.3 152.6 118.9 - - 258.5 18.9 214.1 180.4 146.7 113.0 - -
67 258.0 16.9 250.0 226.7 193.0 159.3 125.6 - 245.0 18.5 240.5 220.7 187.0 153.3 119.6 -
62 249.3 16.7 249.3 249.3 236.2 202.5 168.8 135.1 237.3 18.3 237.3 237.3 224.6 190.9 157.2 123.5
57 246.4 16.5 246.4 246.4 234.3 200.6 166.9 133.3 235.4 18.1 235.4 235.4 223.7 190.0 156.3 122.6
8000
77 297.0 16.7 220.5 160.9 122.0 - - - 282.0 18.2 221.5 154.9 116.0 - - -
72 282.0 16.2 243.8 204.9 166.0 127.1 - - 268.0 17.8 237.8 198.9 160.0 121.1 - -
67 267.0 15.7 267.0 248.9 210.0 171.1 132.2 - 254.0 17.4 254.0 242.9 204.0 165.1 126.2 -
62 258.0 15.6 258.0 258.0 257.0 218.1 179.2 140.4 246.0 17.2 246.0 246.0 245.0 206.1 167.2 128.4
57 255.0 15.4 255.0 255.0 255.0 216.1 177.2 138.4 244.0 17.0 244.0 244.0 244.0 205.1 166.2 127.4
9000
72 295.2 13.7 275.1 228.1 183.8 139.5 - - 280.7 15.3 265.0 220.8 176.5 132.2 - -
67 279.5 13.3 279.5 270.4 232.5 188.2 143.9 - 266.0 15.0 266.0 260.4 225.0 180.7 136.4 -
62 270.1 13.2 270.1 270.1 269.6 225.3 181.0 136.7 257.6 14.8 257.6 257.6 257.1 212.8 168.6 124.3
57 266.9 13.0 266.9 266.9 266.9 222.7 178.4 134.1 255.5 14.6 255.5 255.5 255.5 211.2 167.0 122.7
10000
72 308.4 11.2 306.4 251.2 201.5 151.9 - - 293.3 12.8 292.3 242.6 192.9 143.3 - -
67 292.0 10.8 292.0 292.0 255.0 205.3 155.6 - 278.0 12.5 278.0 278.0 246.0 196.3 146.6 -
62 282.2 10.7 282.2 282.2 282.2 232.5 182.8 133.1 269.2 12.4 269.2 269.2 269.2 219.6 169.9 120.2
57 278.9 10.6 278.9 278.9 278.9 229.2 179.5 129.8 267.1 12.2 267.1 267.1 267.1 217.4 167.7 118.0
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
95°F 105°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
90 85 80 75 70 65 90 85 80 75 70 65
6000
77 247.1 21.9 148.1 119.6 91.1 - - - 232.2 23.3 144.0 115.5 87.0 - - -
72 235.0 21.5 184.6 156.1 127.6 99.0 - - 221.1 22.9 180.0 151.5 123.0 94.5 - -
67 223.0 21.2 221.0 192.5 164.0 135.5 107.0 - 210.0 22.6 209.0 187.5 159.0 130.5 102.0 -
62 216.5 20.9 216.5 216.5 193.0 164.5 136.0 107.5 205.4 22.2 205.4 205.4 183.0 154.5 126.0 97.5
57 215.6 20.6 215.6 215.6 193.0 164.5 136.0 107.5 204.0 21.9 204.0 204.0 182.6 154.1 125.6 97.1
7000
77 257.0 20.8 185.3 134.3 100.6 - - - 241.6 22.3 184.7 132.6 96.0 - - -
72 244.5 20.5 208.2 174.5 140.8 107.1 - - 230.1 21.9 203.1 169.4 135.7 102.0 - -
67 236.0 20.1 231.0 214.7 182.0 147.3 113.6 - 218.5 21.6 218.0 206.2 175.5 141.8 108.1 -
62 225.3 19.8 225.3 225.3 213.0 179.3 145.6 111.9 213.7 21.2 213.7 213.7 202.0 168.3 134.6 100.9
57 224.3 19.6 224.3 224.3 213.0 179.3 145.6 111.9 212.2 21.0 212.2 212.2 201.6 167.9 134.2 100.5
8000
77 267.0 19.7 222.5 148.9 110.0 - - - 251.0 21.3 225.5 149.8 105.0 - - -
72 254.0 19.4 231.8 192.9 154.0 115.1 - - 239.0 20.9 226.3 187.4 148.5 109.6 - -
67 241.0 19.1 241.0 236.9 198.0 159.1 120.2 - 227.0 20.6 227.0 224.9 192.0 153.1 114.2 -
62 234.0 18.8 234.0 234.0 233.0 194.1 155.2 116.4 222.0 20.2 222.0 222.0 221.0 182.1 143.2 104.4
57 233.0 18.6 233.0 233.0 233.0 194.1 155.2 116.4 220.5 20.0 220.5 220.5 220.5 181.6 142.7 103.9
9000
72 266.1 16.9 255.0 213.4 169.2 124.9 - - 251.1 18.4 244.7 208.0 163.7 119.4 - -
67 252.5 16.7 252.5 250.4 217.5 173.2 128.9 - 238.5 18.1 238.5 237.5 211.6 167.3 123.1 -
62 245.2 16.4 245.2 245.2 244.7 200.4 156.1 111.8 233.3 17.8 233.3 233.3 232.8 188.5 144.2 99.9
57 244.1 16.2 244.1 244.1 244.1 199.8 155.6 111.3 231.7 17.6 231.7 231.7 231.7 187.4 143.1 98.8
10000
72 278.2 14.4 278.2 234.0 184.3 134.7 - - 263.2 16.0 263.2 228.5 178.9 129.2 - -
67 264.0 14.2 264.0 264.0 237.0 187.3 137.6 - 250.0 15.7 250.0 250.0 231.3 181.6 131.9 -
62 256.3 14.0 256.3 256.3 256.3 206.7 157.0 107.3 244.5 15.4 244.5 244.5 244.5 194.8 145.1 95.5
57 255.2 13.8 255.2 255.2 255.2 205.6 155.9 106.2 242.8 15.3 242.8 242.8 242.8 193.2 143.5 93.8
