Unitary Products Group 29
TABLE 27: BLOWER PERFORMANCE 10 TON OPTIONAL MOTOR - DOWNSHOT (IMPERIAL)
ESP
(iwg)
Turns Open
012345
CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP
0.2
-----------
-
4966 2666
2.86
4605 2290
2.46
0.4
--
-
--
-
--
-
4919 2473
2.65
4721 2515
2.70
4344 2145
2.30
0.6
--
-
--
-
4929 3022
3.24
4665 2324
2.49
4450 2353 2.52 4048 1991 2.13
0.8
--
-
4908 3197
3.43
4668 2841
3.05
4391 2171 2.33 4151 2183 2.34 3717 1829 1.96
1.0
4915 3456
3.71
4651 3013
3.23
4388 2656
2.85
4096 2015 2.16 3825 2008 2.15 3352 1664 1.78
1.2
4653 3253
3.49
4377 2823
3.03
4089 2467
2.65
3779 1858 1.99 3471 1830 1.96 2951 1499 1.61
1.4
4372 3046
3.27
4087 2631
2.82
3771 2277
2.44
3442 1703 1.83 3090 1652 1.77 - - -
1.6
4070 2837
3.04
3780 2437
2.61
3434 2089
2.24
3084 1552 1.66 - - - - - -
1.8
3748 2629
2.82
3455 2243
2.41
3078 1904
2.04
---------
2.0
3406 2425
2.60
3114 2051
2.20
--
-
---------
2.2
3044 2228
2.39
---------- --- --
TABLE 28: BLOWER PERFORMANCE 10 TON OPTIONAL MOTOR - DOWNSHOT (METRIC)
ES
P
(Pa)
Turns Open
012345
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
50
- - - - - - - - - - - - 2.34 2.67 2.13 2.17 2.29 1.83
100
- - - - - - - - - 2.32 2.47 1.98 2.23 2.51 2.01 2.05 2.15 1.72
149
- - - - - - 2.33 3.02 2.42 2.20 2.32 1.86 2.10 2.35 1.88 1.91 1.99 1.59
199
- - - 2.32 3.20 2.56 2.20 2.84 2.27 2.07 2.17 1.74 1.96 2.18 1.75 1.75 1.83 1.46
249
2.32 3.46 2.76 2.20 3.01 2.41 2.07 2.66 2.12 1.93 2.01 1.61 1.81 2.01 1.61 1.58 1.66 1.33
299
2.20 3.25 2.60 2.07 2.82 2.26 1.93 2.47 1.97 1.78 1.86 1.49 1.64 1.83 1.46 1.39 1.50 1.20
349
2.06 3.05 2.44 1.93 2.63 2.10 1.78 2.28 1.82 1.62 1.70 1.36 1.46 1.65 1.32 - - -
399
1.92 2.84 2.27 1.78 2.44 1.95 1.62 2.09 1.67 1.46 1.55 1.24 - - - - - -
448
1.77 2.63 2.10 1.63 2.24 1.79 1.45 1.90 1.52 - - - - - - - - -
498
1.61 2.43 1.94 1.47 2.05 1.64 - - - - - - - - - - - -
548
1.44 2.23 1.78 - - - - - - - - - - - - - - -
TABLE 29: INDOOR BLOWER SPECIFICATIONS
MODEL
MOTOR MOTOR SHEAVE BLOWER SHEAVE
BELT
HP RPM Eff. SF Frame Datum Dia. (in.) Bore (in.) Model Datum Dia. (in.) Bore (in.) Model
BP090
1-1/2 1725 80% 1.15 56 3.4 - 4.4 7/8 1VM50 7.5 1 AK79 A55
2 1725 80% 1.15 56 3.4 - 4.4 7/8 1VM50 6.5 1 AK69 A53
BP120
2 1725 80% 1.15 56 3.4 - 4.4 7/8 1VM50 7 1 AK74 A54
4 1725 80% 1.15 184T 4.3-5.3 1-1/8 1VP56 6.2 1 BK72 BX56
