TABLE 19: BLOWER PERFORMANCE 10 TON OPTIONAL MOTOR - SIDE DUCT (IMPERIAL)
ESP
(iwg)
Turns Open
012345
CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP CFM Watts BHP
0.4
---------------496024952.68
0.6
- - - - - - - - - - - - 5091 2745 2.94 4646 2314 2.48
0.8
- - - - - - - - - 5078 2937 3.15 4839 2584 2.77 4347 2153 2.31
1.0
- - - - - - 5075 3117 3.34 4767 2730 2.93 4487 2377 2.55 3946 1942 2.08
1.2
- - - 5068 3308 3.55 4742 2881 3.09 4427 2513 2.69 4108 2159 2.32 3501 1723 1.85
1.4
5079 3595 3.86 4787 3105 3.33 4452 2713 2.91 4012 2259 2.42 3665 1926 2.07 - - -
1.6
4739 3316 3.56 4482 2892 3.10 4098 2474 2.65 3543 2006 2.15 3057 1642 1.76 - - -
1.8
4461 3111 3.34 4070 2621 2.81 3552 2160 2.32 - - - - - - - - -
2.0
3997 2782 2.98 3400 2219 2.38 - - - - - - - - - - - -
2.2
3496 2480 2.66 - - - - - - - - - - - - - - -
TABLE 20: BLOWER PERFORMANCE 10 TON OPTIONAL MOTOR - SIDE DUCT (METRIC)
ESP
(Pa)
Turns Open
012345
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
m
3
/s
In
(kW)
Out
(kW)
100
---------------2.342.502.00
149
------------2.402.752.202.192.311.85
199
---------2.402.942.352.282.582.072.052.151.72
249
------2.403.122.492.252.732.182.122.381.901.861.941.55
299
- - - 2.39 3.31 2.65 2.24 2.88 2.30 2.09 2.51 2.01 1.94 2.16 1.73 1.65 1.72 1.38
349
2.40 3.60 2.88 2.26 3.11 2.48 2.10 2.71 2.17 1.89 2.26 1.81 1.73 1.93 1.54 - - -
399
2.24 3.32 2.65 2.12 2.89 2.31 1.93 2.47 1.98 1.67 2.01 1.60 1.44 1.64 1.31 - - -
448
2.113.112.491.922.622.101.682.161.73---------
498
1.892.782.231.602.221.78------------
548
1.652.481.98---------------
