Rinnai Corporation ES38 Manual 7
Control Panel
All buttons beep when operated.
Set Temp
Room Temp
Economy
Temp
Control
Function Lock
Filter
ON/OFF
ON
FUNCTION
LOCK
Lamp is "green"
when this feature
is on.
FILTER LAMP
Flashes when filter
is dirty.
OPERATION LAMP
This lamp turns
"green" when power
is on. Lamp will
change to "red"
when burner is on.
TEMPERATURE
BUTTONS
" " adjust temp. to
lower setting.
" " adjust temp. to
a higher setting.
ENERGY SAVING
BUTTON
Lamp is "green"
when this feature is
activated.
〈CONTROL PANEL 〉
〈INDICATOR DISPLAY 〉
>
>
TEMPERATURE
DISPLAY
SHOWS EITHER THE
TEMPERATURE OR
CODED ERROR
MESSAGES.
ON/OFF BUTTON
Easy operation
One touch ignition
