38 Rinnai Corporation ES38 Manual
Parts List
ITEM PART NUMBER
QTY
1004RFA
Beige
1004FA-W
White
001 1001F-073-9 SIDE PANEL I 2
1001F-073-4 SIDE PANEL D 2
002 1004F-2071-6 TOP PLATE F 1
1004F-2071-3 TOP PLATE C 1
003 1004F-2073-10 OPERATION LID J 1
1004F-2073-6 OPERATION LID F 1
004 556F-558-2 FULCRUM 1 1
005 ZUAA02SZ STOPPER 1 1
006 1001F-1514-2 DECORATION PANEL ASS’Y C 1
1001F-1514-3 DECORATION PANEL ASS’Y D 1
007 1001F-160-9 FRONT PANEL ASS’Y I 1
1001F-160-5 FRONT PANEL ASS’Y E 1
008
1004F-2080 ESCUTCHEON PANEL 1
1004F-2087 ESCUTCHEON PANEL B 1
009 1001F-084-2 LOUVER SUPPORT TRIM B 1
1001F-084-3 LOUVER SUPPORT TRIM C 1
010 1001F-163-2 LOUVER ASS’Y B 1
1001F-1323 LOUVER ASS’Y 1
011 1001F-162-7 BOTTOM TRIM ASS’Y G 1
1001F-162-4 BOTTOM TRIM ASS’Y D 1
012 1001F-164-4 FILLER ASS’Y D 1
1001F-1322 FILLER ASS’Y 1
013 1001F-078 LOUVER DOOR HINGES 1 1
014 551F-015 FILLER 1 1
015 RHF300-185-1 MAGNET 1
1
016 1001F-1410-2 BACK SPACER LEFT A 1
1001F-1410-9 BACK SPACER LEFT E 1
017 1001F-1411-4 BACK SPACER B RIGHT D 1
1001F-1411-5 BACK SPACER B RIGHT E 1
019 1001F-165-10 BACK SPACER UPPER ASS’Y J 1
1001F-165-13 BACK SPACER UPPER ASS’Y M 1
020 1004F-228 AIR FILTER ASS’Y 2 2
021 1001F-092 BACK SPACER SUPPORT 2 2
022 1004F-825 WALL BRACKET B 2 2
024 1001F-157 LEG ASS’Y 2 2
025 550F-0220 RUBBER BRACKET ASS’Y 2 2
026 550F-0225
BASE SUPPORT RUBBER 4 4
027 1004F-2111 LAMP HOUSE 1 1
100 1001F-150-3 HIGH BURNER LEFT ASS’Y C 1 1
101 1001F-144-3 HIGH BURNER RIGHT ASS’Y C 1 1
102 1001F-147-3 LOW BURNER ASS’Y C 1 1
103 RHF250-075 DAMPER PANEL 2 2
104 1001F-049 BURNER BRACKET PACKING 2 2
105 1004F-2022 BURNER BRACKET LEFT ASS’Y 1 1
106 1004F-2020 BURNER BRACKET RIGHT ASS’Y 1 1
107 1001F-104-2 FLAME ROD 1 1
108 RHF250-038 ELECTRODE CLIP
1 1
109 1001F-216 ELECTRODE 1 1
110 1001F-168 ELECTRODE BRACKET 1 1
111 1001F-175 ELECTRODE SEAL PACKING 1 1
PART NAME
