4 www.petsafe.net
Key Defi nitions
Remote Transmitter: Transmits the radio signal to the Receiver Collar. It is waterproof.
Transmitter Indicator Light: Indicates that a button is pressed and also serves as a low-battery indicator.
Intensity Dial: Provides multiple Stimulation Levels so you can match the correction to your pet’s
temperament.
Upper Button: Delivers an Audible Tone for one second then Continuous Stimulation at the level set by
the Intensity Dial.
Lower Button: Delivers an Audible Tone for one second then Continuous Stimulation at a level slightly
higher than the Intensity Dial. Note: This button will not deliver Stimulation higher than level 8. For example, if
the Intensity Dial is set to 8, pushing the Lower Button will not deliver a higher Stimulation Level.
Side Button: Delivers an Audible Tone only.
Charging Jack: For connecting the charger. Although the Remote Transmitter is waterproof without the
charger cover, keep the cover in place when not charging to keep debris out of the opening.
Receiver Collar: Receives the radio signal from the Remote Transmitter. It is waterproof.
On/Off Button: Momentarily pressing and releasing this button turns the Receiver Collar on and off.
Contact Points: The contacts through which the Receiver Collar delivers Stimulation.
Receiver Indicator Light: Indicates when the Receiver Collar has been turned on or off and also serves as
a low-battery indicator.
Continuous Stimulation: You control when and how long Stimulation is delivered to your pet through
the Receiver Collar’s Contact Points. Before the Stimulation, your pet will hear an Audible Tone. For safety,
when the Upper or Lower Button is pressed for 8 seconds or more, the Remote Transmitter will “time-out.”
The button will need to be released and pressed again before additional Stimulation can be delivered.
Audible Tone: Use the Side Button to send an Audible Tone to your pet without Stimulation.
LDT-433 Receiver Collar
Receiver
Indicator
Light
Battery
Lid
ON/OFF
Button
Contact
Points
Antenna
BDT-433 Receiver Collar
Receiver
Indicator
Light
Battery
Lid
ON/OFF
Button
Contact
Points
Antenna
Remote Transmitter
1
2
3
4
5
6
7
8
Transmitter
Indicator
Light
Side Button
Upper Button
Transmitter Antenna
Intensity Dial
Lower Button
Charging Jack
(with cover)
