Model
Dimensions – in (mm) Minimum Duct
A B C Length – in. (mm)
BSD 12 2 (51) 1.75 (44) 10 (254) 12 (305)
BSD 18 2 (51) 1.75 (44) 16 (406) 18 (457)
BSD 24 2.25 (57) 1.75 (44) 20 (508) 24 (609)
BSD 30 2.25 (57) 1.75 (44) 26 (660) 30 (762)
BSD 36 2.25 (57) 1.75 (44) 32 (813) 36 (914)
BSD 42 2.5 (64) 2 (51) 38 (965) 42 (1066)
BSD 48 2.5 (64) 2 (51) 44 (1118) 48 (1219)
BSD 54 2.5 (64) 2 (51) 50 (1270) 54 (1371)
BSD 60 3 (76) 2.5 (64) 56 (1422) 60 (1524)
BSD 66 3 (76) 2.5 (64) 62 (1575) 66 (1676)
BSD 72 3 (76) 2.5 (64) 68 (1727) 72 (1828)
BSD 78 4 (102) 3.5 (89) 47 (1880) 78 (1981)
BSD 84 4 (102) 3.5 (89) 80 (2032) 84 (2133)
BSD 90 4 (102) 3.5 (89) 86 (2184) 90 (2286)
BSD 96 4 (102) 3.5 (89) 92 (2337) 96 (2438)
BSD 102 4 (102) 3.5 (89) 98 (2489) 102 (2590)
NOTES:
1. ASD Maximum rated output 25 lbs/hr (11.4 kg/hr).
2. BSD Maximum rated output 35 lbs/hr (15.9 kg/hr).
3. CSD Maximum rated output 115 lbs/hr (52.3 kg/hr).
4. Steam Distributors tube made of stainless steel.
5. Steam inlet and end cap made of fine rated plastic.
6. Distributor is adjustable for horizontal or downflow application.
Figure 7. Distributor Dimensions (Sheet 2 of 3)
