WARNING: To reduce the risk of
shock, always unplug humidifier
before cleaning or servicing.
WARNING: To reduce the risk of fire
or shock hazard, do not pour or spill
water into control or motor area.
If controls get wet, let them dry com-
pletely and have unit checked by
authorized service personnel before
plugging in.
This humidifier is designed for use with
the water bottle located to the right of the
upper grill. The water bottle holds 1.9
gallons of water. The humidifier should be
positioned where it will be operating.
To fill the whole house humidifier, grasp
the bottle handle at the top of the bottle
and lift it straight up and away from
humidifier base. Take care not to bump
or damage spring valve assembly on bot-
tom of bottle.
NOTE: If it is desired to use approved
bacteriostat, follow directions correctly.
The bottle of the whole house humidifier
will hold 1.9 gallons of water.
The water bottle is designed with a Side
Fill Cap. Remove the Cap on the side
of the water bottle by twisting counter-
clockwise.
Place the opening of the water bottle
under a water faucet and fill. If desired,
add liquid bacteriostat to help control the
build up of bacteria and algae. Do not
use solid water treatments. Solid debris
could make the lower valve leak.
Install the “Side Fill Cap” by twisting
clockwise. Hand tighten only.
Check for possible leaks by perform-
ing the following:
1. Grasp bottle handle and hold the bot-
tle upright over a sink.
2. Press up on valve plunger for about
one second to let out a little water.
3. Release the plunger.
4. Listen for air bubbles. Look for leaks
around the “Side Fill Cap” and valve
plunger.
5. If you hear air bubbles or see leaks,
retighten the “Cap” and repeat steps
1-4.
Wipe off excess water from the bottle.
Water Fill
6
Turn Counterclockwise
to Remove “Side Fill
Cap”
Spring Valve Assembly
Base
Bottle
