Carefully remove the humidifier and all
other contents from the carton.
There is a black strip that contains six
pads for the bottom of the humidifier.
Remove each pad and place one on
each of the six legs on the bottom of the
base as shown, by the solid dots.
Once installed return the humidifier to
it’s original state and proceed to
“Locations Instructions
”.
Your new MoistAir humidifier is designed
to satisfy home humidity requirements
through the principle of evaporation of
water in the air.
After water is added to the humidifier, the
filter begins to soak up the water and will
become saturated in approximately 30
minutes. Air drawn in through the open-
ings in the lower housing passes through
the filter by means of a circulation fan. As
air passes through the filter, moisture is
absorbed into the air and then released in
the form of vapor. No water droplets will
enter the home. All evaporation into the
air takes place in the humidifier, which
means that the residue left by evaporat-
ing water is not passed into the home,
but remains in the filter.
This natural process of evaporation helps
eliminate the chance of white dust in the
humidified output air.
CAUTION: Use only liquid EPA
Registered Bacteriostat available
from local Retail store. Under no cir-
cumstances should you use water
treatment products designed for
Roto belt or Ultrasonic humidifiers.
CAUTION: To reduce the risk of
injury, fire or damage to humidifier,
use only cleaners specifically recom-
mended for humidifiers. Never use
flammable, combustible or poisonous
materials to clean your humidifier. To
reduce the risk of scalds and dam-
age to humidifier, never put hot water
in humidifier.
Humidifier Operations
Assembly
4
Humidified air is
then released
through the top
Dry air
enters
through the
louvers in
the housing
2
1
5
4
3
6
