Location Instructions
WARNING: For your own safety, do
not use humidifier if any parts are
damaged or missing.
Step 1
Place humidifier on a flat level surface in
an area of house where most humidity is
needed, or one which would likely result in
moist air being circulated throughout the
house such as near a cold air return.
Placing the unit level is very important.
Special attention should be given to
unit's level if the humidifier is located on
carpeting.
Moist air (humidity) produced will disperse
into the whole house, but the area closest
to the unit will have the highest humidity. If
the unit is positioned close to a window,
condensation may form on the window
pane. If this is not appropriate the unit
should be repositioned in another location.
NOTE: Due to release of cool, moist air
from humidifier, it is best to direct air away
from home thermostat and hot air regis-
ters. It is best to position humidifier next to
an inside wall. Hot air registers and cold
air from outside walls can affect the effi-
ciencies of the controls. Unit should not
be placed where warm air from a hot air
register blows directly on unit.
Step 2
The humidifier should be positioned with
the back (cord exit side) and left side, at
least 2 inches away from the wall. Air
needs to enter through all of the louvers in
the housing assembly in order for the
humidifier to operate at peak efficiency.
Locate nearest 120V A.C. wall socket in
the location desired, preferably on inside
wall. With the humidifier in the desired
location, route the electrical cord safely
so no one will trip or upset the humidifi-
er. Plug in the electrical cord.
WARNING: To reduce the risk of fire
or shock hazard, humidifier should
be plugged directly into a 120V A.C.
outlet. Do not use extension cords.
To reduce the risk of electrical shock,
this humidifier has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse plug. If it still does not fit, con-
tact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.
Electrical Hook-Up
5
At least 2"
from wall
SP6549 Manual 71235 7/12/05 3:17 PM Page 5
