Lennox Hearth ME43 Indoor Fireplace User Manual



22
Attic Radiation Shield, ACRSA H0487
Wall Radiation Shield, 30, AC, RSM30 ACRSM30
Insulated Wall Radiation Shield, 30, ACRSMI30 H0489
Chimney Outside Air Kit (Flex, Insulation, Outside
Register And Coupling), ACZI
H1967
Notes: AC Chimney is Not recommended at elevations above 4000
feet or in cold climates.
ME43 COMPONENTS LISTS
Replacement Parts
Description Cat. No.
Refractory PR-SR2028
Back Refractory PR-SR2027
Right Side Refractory PR-SR2025D
Left Side Refractory PR-SR2025G
Bottom Refractory PR-SR1722
Front Refractory Ash Lip PR-SR2026
Log Support Grate PR-HELS43
Top Louver PR-SR15P
Bottom Louver PR-SR15P
Louver Hinges PR-PIVOT
Rigid Firescreen (Right) PR-PARETIND-1
Rigid Firescreen (Left) PR-PARETING-1
Black Door (Left) PR-SR2060GNO
Black Door (Right) PR-SR2060DNO
Gold Plated Door (Left) PR-SR2060GOR
Gold Plated Door (Right) PR-SR2060DOR
Wooden Handle PR-SAC#69
Ceramic Glass Panel PR-VC10
Snap Disc, Blower VTU
Door Gasket Assembly PR-GASKPORTEHE-1
Damper PR-DAMPER43
Touch-up Paint, Aerosol, Black Metallic
SBMB6309
70K99
APPENDIX
SPECIFICATIONS
Weight 343 lbs
Height 42"
Width 43"
Depth 26-5/8"
Chimney weight ASHT+ 8.75 lb/feet
Chimney weight S-2100+ 13.2 lb/feet
Chimney weight AC 3.75 lb/feet
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a
safe installation :
Side wall: 18" (457mm)
Ceiling: 7 feet (2135mm)
measured from the base
of the fireplace
Fireplace enclosure: Bottom: 0"
Side: 0"
Back: 0"
Top: Do not fill the space
above the fireplace with
any material (7 feet
measured from the base
of the fireplace)
Chimney: 2" (50mm)
Mantel: 48" (1219mm) from the
base of the fireplace
