Lennox Hearth ME43 Indoor Fireplace User Manual



21
ME43 COMPONENTS LISTS
AC Chimney
(Air Cooled - 8” I.D.,13” O.D.)
Description Cat./Part No.
AC Starter Adaptors
An AC Adaptor Is Needed To Convert Fireplace For Use With AC Chimney
Starter Section (adaptor), 8” AC, AC8SB H3801
Starter 30
Elbow, AC, AC8SB30 H3802
Outside Air Kit
Required for AC chimney installation
Chimney Outside Air kit (Flex, Insulation, Outside
Register and coupling), ACZI
H1967
Lengths & Misc. Chimney Components
18” Length, Dia. x 12” Long, AC6L18 H3798
36” Length, Dia. x 36” Long, AC8L36 H3799
48” Length, Dia. x 48” Long, AC8L48 H3800
15
Elbow, Dia., AC8E15 H3795
30
Elbow, Dia., AC8E30 H3796
Rain Termination Cap, Dia., AC8CPR H3794
Spark Arrester Screen (universal spark arrester band), PE+ PE
Wall Band, BM H0484
Supports
Offset Support, SO H0480
Support Section, AC8SL H3804
Roof Support, ST H0482
Roof Brace, BS2 H0483
Roof Flashings
Flat roof flashing, ACF H0494
1/12 - 7/12 (
5
-3
0
), AC, Adj. Roof Flashing, FA H0495
8/12 - 12/12 (3
0 - 45
), AC,Adj. Roof Flashing, FB H0496
Storm collar, ACFC H0500
Misc.
Telescopic attic radiation shield, ACRST H0498
Firestop, ACBF H0485
Radiation Shield, ACRS H0486
8”
8”
8”
8”
8”
8”
8”
Secure Te
mp
High Temp. Insulated Stainless Steel Chimney
8”
Diameter, Listed to CAN/UCL-S604 & UL-103HT at 2100
F
Description
Part/Cat. No.
Lengths & Misc. Chimney Components
8” length, 8” Dia., 8L8 8L8
12” length, 8” Dia., 8L12 8L12
18” length, 8” Dia., 8L18 8L18
24” length, 8” Dia., 8L24 8L24
36” length, 8” Dia., 8L36 8L36
48” length, 8” Dia., 8L48 8L48
Adjustable Length
12”, 8”
Dia., 8LA 8LA
15
elbow,
8”
Dia., 8E15 8E15
30
elbow, Dia., 8E30 8E30
Rain Termination Cap, Dia., 8CC 8CC
Wall Band BM
Supports
Offset Support, SO SO
Roof Support, ST ST
Roof Brace, BS2 BS2
Firestops
Telescopic Attic Radiation Shield, 8TRS 8TRS
Firestop, 8BF 8BF
Radiation Shield, 8RS 8RS
Insulated Attic Radiation Shield, 8RSA 8RSA
Insulated Wall Radiation Shield, 8RSM 8RSM
Roof Flashings
Flat Roof Flashing, 8FR 8FR
1/12 - 7/12 (
5
-
30
), 8FAR 8FAR
8/12 - 12/12 (3
0
), 8FBR 8FBR
Storm Collar, 8FC 8FC
TM
8”
8”
-
45
ASHT+
