ME43 COMPONENTS LISTS
Installation Accessories
Description Cat./ Part No.
Outside Air Kit (Required - included with fireplace)
Outside Air Coupler to connect outside air UZI to fireplace,
UZIAD
UZIDF
Outside Air Ducting - includes 4" insulated flex x 10' long,
UZI
UZI
Fireplace Options
Trim Kit - Gold H3426
Trim Kit - Brushed Nickel H3395
Door Capping - Gold H3393
Door Capping - Brushed Nickel H3394
Blower UZY5
Blower motor speed control VRUW
Forced Air Heating Kit
Starter Kit: For wall or furnace installations. Includes
blower (BISZY), flex adaptor and two clamps (BISAF),
blower variable speed control (VRUW), thermo disc (VTU),
blower flex adaptor (BISAVF), and back draft damper
(BISBD)
BISFWK-1
Flex 5 inches ID x 15 feet Long 5FLEX15
Flex 5 inches ID x 25 feet Long 5FLEX25
Starter Kit Separate Components
Blower flex adaptor, includes damper (BISBD) BISAVF
Blower - 250 CFM BISZY
Flex adaptor and two clamps for fireplace connection BISAF
Blower motor speed control VRUW
Thermo disc - turns motor on when fireplace hot and off
when cool
VTU
Back draft damper - prevents air blowing from furnace into
fireplace
BISBD
Options
Heating/Cooling thermostat - 110 volt HCTW
Fl
ex -
choose 15 feet or 25 feet depending on installation
Fireplace Model ME43 - Approved Venting Components
- 8” diameter chimney - Model ASHT+, S-2100+, HT6000+, HT6103+
or AC manufactured by Security Chimneys International only.
Notes:
(P
rojet NovaTemp ) HT6000+ is equivalent to S-2100+
(Projet NovaTemp ) HT6103+ is equivalent to ASHT+
This appliance is equiped with the ASHT Chimney Adaptor. When other
chimney is used, a chimney adaptor for that chimney will be required.
Chimney Adaptor (S-2100+ / HT6000+) for CANADA ONLY -
If you want to
install a S-2100+ / HT6000+ chimney, an adaptor is available (8UCA).
AC Chimney is Not recommended at elevations above 4000 feet or
in cold climates where temperatures are likely to fall below 32°
F (0° C).
When using AC chimney, an AC8SB starter section
must be used
before installing an elbow.
When an offset is needed
immediately off the
top of the fireplace, a starter section
(AC8SB30)
is available.
