CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe
installation;
Side wall:
17” (324 mm) measured from the fireplace side
Ceiling: 6’ 8” (2,032 mm) measured from the base of the fireplace
Fireplace enclosure:
Bottom: 0”
Side: 0’’ to spacer
Back: 0’’ to spacer
Top: Do not fill the space above the fireplace with any material
(Except the wood framing. See Page 9, Figure 8
)
Chimney: 2” (50mm)
Mantel: 39’’ (990mm) measured from the base of the fireplace.
SPECIFICATIONSREPLACEMENT PARTS LIST
Cat. No. Model Description
H7162 Ladera-BK Ladera EPA Wood-Burning Fireplace
H7230 Ladera-BN Ladera EPA Wood-Burning F/P Br Nickel
Product Reference Information
Weight 215 lbs
Height 37-5/8”
Width 32-3/4”
Depth 22-1/2”
Firebox W x H x D - measured in front 19-1/2” x 13-1/4” x 12”
Chimney Weight ASHT (6” dia) 6.25 lb/ft.
Chimney Weight AC (6” dia.) 3.25 lb/ft.
Chimney weight S-2100+ (6” dia.) 10.8 lb/ft.
Ladera™ Replacement Parts
Description Part/Cat. No.
Andiron (2 pieces) PR-SR2897
Bottom refractory PR-SR2825
Back refractory PR-SR2826
Left side refractory PR-SR2828
Right side refractory PR-SR2827
Front refractory (2 pieces) PR-SR2829
Secondary air tube (back) PR-SR2906
Secondary air tube (middle or front) PR-SR2830
Tube lock (2 pieces) PR-SR2873
Fireplace left side PR-SR2848
Fireplace right side PR-SR2849
Fireplace top PR-SR2847
Fireplace back PR-SR2846
Top flex protector PR-SR2877
Door wooden handle PR-SR2903
Door locking mechanism PR-SR2855
Door hinges PR-SR1933
Ceramic glass PR-SR2899
Gasket, glass PR-SR1685H
Gasket, door PR-SR1823O
Blower PR-UZY6
Door, complete black PR-SR2898
Door, complete brushed nickel PR-SR2898BN
Touch-up Paint, Aerosol, Black Metallic SBMB6309 70K99
24
