CHIMNEY - PARTS AND COMPONENTS LISTS
Installation Accessories
Description Cat./ Part No.
Outside Air Kit
Outside Air Coupler To Connect Outside Air (UZI) To Fire-
place, UZIAD
UZIAD
Outside Air Ducting - includes 4” insulated flex x 10’ long, UZI UZI
Gravity Kit
Complete double ducting system including: 2 elbows 90º, 2
telescopic lengths, 2 grill supports and 2 black grills
7B30ZK-1
Gravity Kit Accessories
Black grill with support, Part# 7B30ZO 7B30ZO
Brass grill (for 7B30ZK), 7B30ZGB 7B30ZGB
Elbow 90º, 8” dia., 7B26ZE90 7B26ZE90
Elbow 45º, 8” dia., 7B26ZE45 7B26ZE45
Telescopic length, 8” dia., 7B26ZLA 7B26ZLA
Adjustable length 8” dia (2” - 5”), 7B26ZL2A 7B26ZL2A
Wall Radiation shield, 7B26ZR 7B26ZR
Length five (5) feet, 8KL5 8KL5
Length four (4) feet, 8KL4 8KL4
Length three (3) feet, 8KL3 8KL3
Length two (2) feet, 8KL2 8KL2
Length one (1) feet, 8KL1 8KL1
Fireplace Kits
Rigid firescreen BNZN
Central Forced Air Kit Accessories u
Central Forced Air Kit, Central forced air kit including: blower
(BISZY), flex adaptor (BISAF), 2 clamps, variable speed
control (VRUW), thermo-disk (VTU), fan to flexible pipe
adapter (BISAVF), back draft damper (BISBD), aluminium
tape, BISFWK-1
BISFWK-1
Fireplace to Flex adaptor and 2 clamps, BISAF BISAF
Flexible pipe 5” I.D. x 15 ft. Long, 5FLEX15 5FLEX15
Flexible pipe 5” I.D. x 30 ft. Long, 5FLEX25 5FLEX25
Blower 250 CFM for central forced air kit, BISZY BISZY
Blower variable speed control with decorative wall plate for
(BISZY), VRUW
VRUW
Thermo-disk, on/off blower control (for BISZY), VTU VTU
Blower to flexible pipe adaptor, BISAVF BISAVF
Heating and cooling thermostat, HCTW HCTW
Backdraft damper, BISBD BISBD
OPTIONAL INSTALLATION ACCESSORIES
Fireplace Model Ladera - Approved Venting Components manufactured
by Security Chimneys International only.
• 6” diameter chimney - AC (air cooled), Secure Temp™ ASHT+ (or Nova
Temp™ HT6103+) and Secure Temp S-2100+ (or Nova Temp HT6000+).
• 6” diameter chimney for relining masonry chimneys - TUBINOX chimney (or
PROJET SS), 6” diameter with adaptor for installation in a masonry chimney.
• 7” diameter chimney - Secure Temp™ ASHT+ (or NovaTemp™ HT6103+).
Notes:
jNova Temp HT6000+ is equivalent to Secure Temp S-2100+
kNova Temp HT6103+ is equivalent to Secure Temp ASHT+
lThis appliance is equipped with the ASHT Chimney Adaptor. When other
chimney is used, a chimney adaptor for that chimney will be required.
m Chimney Adaptor (S-2100+ / HT6000+) for CANADA ONLY -
If you want to
install a S-2100+ / HT6000+ chimney, an adaptor is available (6UCA).
nAC Chimney is NOT recommended at elevations above 4,000 feet or in cold
climates (climates where temperatures will fall below 32° F / 0° C). When
using AC chimney, an AC6SB starter section must be used before installing
an elbow. When an offset is needed immediately off the top of the fireplace,
an elbow starter section (AC6SB30) is available.
oChimney Adaptor 7in - If you want to install a 7in ASHT / HT6103 chimney,
an adaptor is available (6AW7).
Cast Surround Kit
Description Cat./ Part No.
Cast Surround Kit, Ladera-CSK H7303
Secure Temp ASHT 1” High Temp. Insulated Stainless Steel Chimney
6” I.D. and 8” O.D., Double-Wall Stainl. Steel, Listed to CAN/UCL-S604 and UL-103HT
Description Part/Cat. No.
Lengths and Misc. Chimney Components
8” length, 6” Dia., 6L8 6L8
12” length, 6” Dia., 6L12 6L12
18” length, 6” Dia., 6L18 6L18
24” length, 6” Dia., 6L24 6L24
36” length, 6” Dia., 6L36 6L36
48” length, 6” Dia., 6L48 6L48
Adjustable Length 12”, 6” Dia., 6LA 6LA
15º elbow, 6” Dia., 6E15 6E15
30º elbow, 6” Dia., 6E30 6E30
Rain Termination Cap, 6” Dia., 6CC 6CC
Spark Arrester Screen (universal spark arrester band), PE PE
Wall Band, BM BM
Supports
Offset Support, SO SO
Roof Support, ST ST
Roof Brace, BS2 BS2
Firestops
Firestop, 6BF 6BF
Radiation Shield, 6RS 6RS
Insulated Attic Radiation Shield, 6RSA 6RSA
Insulated Wall Radiation Shield, 6RSM 6RSM
Insulated Wall Radiation Shield, 30º, 6RSMI30 6RSMI30
Uninsulated Wall Radiation Shield, 30º, 6RSM30 6RSM30
Attic Radiation Shield H0487
Roof Flashings
Flat Roof Flashing, 6FR 6FR
1/12 - 7/12 (5º - 30º), 6FAR 6FAR
8/12 - 12/12 (30º - 45º), 6FBR 6FBR
Storm Collar, 6FC 6FC
Chimney Adaptors
Chimney Adaptor, 6” (S2100, HT6000) 6UCA
Chimney Adaptor, 6 to 7” (ASHT, HT6103) 6AW7
uNot tested under EPA certification. If installed, this appliance no
longer qualifies for EPA certification.
