Janome 350E Sewing Machine User Manual



15
Embroidery Hoops
(A) Embroidery Hoop A:
This is the standard size hoop, with a 12.6 cm (5”) by
11 cm (4 3/8”) embroidery area for sewing PC Card
embroidery designs etc.
(B) Embroidery Hoop B:
This is the large-size hoop, with a 20 cm (8”) by 14 cm
(5 1/2”) embroidery area for sewing large-size designs
and combined designs.
q Outer hoop
w Inner hoop
e Attaching knob
r Hoop tightening screw
Templates
When positioning the fabric into the hoop, use the
template to align the centerlines on the fabric with the
center of the hoop. First mark the centerlines on the
fabric and place the fabric on the outer hoop. Place the
inner hoop and template over the fabric and adjust the
fabric placement.
q Starting point for built-in and PC Card designs
w Starting point for monogramming in horizontal
placement
e Starting point for Memory Card No. 102 and
up for Memory Craft 5700/9000.
r Starting point for monogramming in vertical
placement
t Embroidery boundary for built-in and PC Card
designs.
NOTE:
The four indentations on the template do not
correspond with reference lines.
y Indentations for positioning the template
(A)
(B)
q
w
e
r
t
y
q
w
e
r
y
q
w
e
r
q
