18

FEEDERDOESNOTFEED

1.Nopelletsinhopper.

2.FeedmotorwillnotrununtilESP

senses165deg.F.Maybeyoudidnotput

enoughpelletsintheburnpotbeforelighting

thefire.

3.Feedmotorhasfailed.

4.Somethingisrestrictingflowinthehopper

orcausingtheslideplatetostick.

5.Fireboxdraftmaybetoolowforlowdraft

pressure switch in feeder circuit to operate.

Checkforcloseddoors,looseormissinggas-

ket on doors or hopper  lid, faulty pressure

switch.

PARTIALLYBURNED PELLETS

1.Feedratetoohigh.

2.Drafttoolow.(Checkburnpotclean- outslide

anddoorgasket).

3.Burnpotorheatexchangertubesmayneed

tobecleaned.

4.Combinationofalltheabove.

SMOKE SMELL

Sealtheventpipejointsandconnectiontostove

withsilicone.

FIREHASGONEOUT

1.Nopelletsinhopper.

2.Feedratetoolow.

3.Somethingisrestrictingfuelflow.

4.Feedmotorordraftmotorhasfailed.

5.Powerfailureorblownfuse.

SMOKEISVISIBLECOMINGOUTOFVENT

1.Air-fuelratioistoorich.

A.Feedratetoohigh.

B.Drafttoolowcausedbyagasketleak.

LOWHEAT OUTPUT

1.Feedratetoolow

2.Drafttoolowbecauseofgasketleak.

3.Poorqualityordamppellets

4.Combinationof1.and2.

CleaningBurnPot

Wheneveryourstoveisnotburning,takethe

opportunitytoscrapetheburnpottoremovecarbon

buildup.Avacuumcleanerishandytoremovethe

residue. Be sure the stove is cold if you use a

vacuum.

Carbonbuildupcanbescrapedloosewiththe

fireburningusingthespecialtoolprovidedwithyour

stove.Scrapethefloorandsidesoftheburnpot.

Thecarbonwillbepushedoutbytheincomingfuel.

Alwayswearglovestodothis.

RemovingAshes

TurntheStoveTempDialtonumber1approxi-

mately30minutesbefore removingashes.Thiswill

resultinacoolerstoveandashpan.

MaximumTurbo settings are not neededin

mostcases.Operatinginthenormalrangeisrec-

ommendedwhenmaximumheatoutputisnotre-

quired.TheESPprobepreventsthestovefrombe-

ingover-fired.

Keepthestovefreeofdustanddirt.

HelpfulHints

Fuel

Pelletfuelsareputinto3categoriesintermsofashcontent.Premiumat1%orless,Standardat3%

orlessandallothersat3%ormore.

TheP61iscapableofburningall3categoriesofpelletsduetoapatentedfeederandburnpot

system.

Itshouldbenoted,however,thathigherashcontentwillrequiremorefrequentashremovalandmay

providelessBTU'sperlb.Normally,standardandhighashpelletscostlessthanpremiumpelletsandcan

becosteffectivewhenburnedintheP61.

Themoisturecontentmustnotexceed8%.HighermoisturewillrobBTU'sandmaynotburnproperly.

Trouble-Shooting
