SKU 93662 For technical questions, please call 1-800-444-3353. Page 10
OPERATING INSTRUCTIONS
To Properly Locate The Water Pump:
1. WARNING! Use this Water Pump outdoors only. Do not operate the Water
Pump in a closed area or in a poorly ventilated area. When running, the Engine
of this Water Pump produces carbon monoxide, a colorless, odorless, toxic
fume that, when inhaled, can cause serious personal injury or death.
Keep your work area clean and well lit.2. Cluttered and dark areas invite acci-
dents.
3. Do not operate the Water Pump in explosive atmospheres, such as
in the presence of ammable liquids, gases, or dust. The Water Pump
and its Engine can create sparks which may ignite the dust or fumes.
Make sure the Water Pump is located on a at, level, sturdy surface capable of sup-4.
porting the weight of the Water Pump and any additional tools and equipment.
Route the Intake Hose with its Intake Filter (21) fully immersed in the water supply 5.
source. Then, make sure to secure the Intake Hose in place to keep it from mov-
ing once the Water Pump is turned on. NOTE: The maximum suction lift of the
Water Pump is 26 feet. The Intake Hose should be kept as short as possible for
more efcient operation.
Route the Discharge Hose to the desired discharge location. If necessary, connect 6.
additional Discharge Hoses to direct the discharge to the desired location. Then,
secure the Discharge Hose in place to keep it from moving once the Water Pump
is turned on.
Note: The maximum discharge length of the Water Pump is 86 feet. The Discharge Hose
should be kept as short as possible for more efcient operation.
To Prime The Water Pump:
The Water Pump 1. MUST be primed with clean water prior to each use of the Pump.
To Prime the Water Pump, unscrew and remove the Priming Cap (11) located at
the top of the Discharge Flange (10). (See Figure D, next page.)
Fill the Discharge Flange (10) to its top with clean water. Then, replace the 2.
Priming Cap (11). (See Figure D.)
