14
You can adjust the air flow direction to increase
your comfort
When SWING is selected, the flap swinging range depends
on the operation mode.(See the figure.)
COOL/DRY
HEAT
NOTE
CAUTION
ATTENTION
Adjusting the louver
ATTENTION
Be careful when adjusting the louver. Inside the air
outlet, a fan is rotating at a high speed.
Hold the knob and move the louver.
(You will find a knob on the left-side and the right-side blades
When adjusting the flap by hand, turn off the unit,
and use the remote controller to restart the unit.
Do not try to adjust the flap by hand.
When adjusting by hand, the mechanism may not
operate properly or condensation may drip from air
outlets
Unless [SWING] is selected, you should set the flap at a
near-horizontal angle in HEAT mode and at a upward
position in COOL or DRY mode to obtain the best
performance.
Operation
Adjusting the Air Flow Direction
Adjusting the flap
Notes on flap angles
