6 www.goodmanmfg.com SS-GSX16
SS-GSX16 www.goodmanmfg.com 7
Product SPecificationS
Product SPecificationS
EXpAndEd coolinG dAtA — GSX160241f* / cA*f3636*6d*+tXV
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
700
MBh 22.1 22.9 25.1 - 21.6 22.4 24.5 - 21.1 21.9 23.9 - 20.6 21.3 23.4 - 19.5 20.3 22.2 - 18.1 18.8 20.6 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 21 18 13 - 20 18 13 - 19 16 12 -
kW 1.54 1.57 1.61 - 1.64 1.67 1.72 - 1.74 1.77 1.82 - 1.82 1.86 1.91 - 1.89 1.93 1.99 - 1.95 1.99 2.05 -
Amps 5.7 5.8 6.0 - 6.1 6.3 6.5 - 6.6 6.8 7.0 - 7.1 7.3 7.5 - 7.5 7.7 8.0 - 8.0 8.2 8.4 -
Hi PR 205 221 233 - 230 248 262 - 262 282 298 - 298 321 339 - 336 361 381 - 371 399 421 -
Lo PR 103 109 119 - 109 116 126 - 113 120 131 - 119 126 138 - 124 132 144 - 129 137 149 -
750
MBh 22.5 23.3 25.5 - 21.9 22.7 24.9 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 19.8 20.6 22.5 - 18.4 19.1 20.9 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
kW 1.56 1.59 1.63 - 1.66 1.70 1.75 - 1.76 1.79 1.85 - 1.84 1.88 1.94 - 1.91 1.95 2.01 - 1.98 2.02 2.08 -
Amps 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 - 8.1 8.3 8.6 -
Hi PR 209 225 237 - 234 252 266 - 267 287 303 - 304 327 345 - 342 368 388 - 377 406 429 -
Lo PR 105 111 122 - 111 118 128 - 115 122 133 - 121 128 140 - 126 135 147 - 131 139 152 -
900
MBh 23.2 24.1 26.4 - 22.7 23.5 25.8 - 22.2 23.0 25.2
- 21.6 22.4 24.5 - 20.5 21.3 23.3 - 19.0 19.7 21.6 -
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
kW 1.58 1.61 1.65 - 1.69 1.72 1.77 - 1.78 1.82 1.87 - 1.87 1.91 1.97 - 1.94 1.98 2.04 - 2.01 2.05 2.11 -
Amps
5.9 6.0 6.2 - 6.3 6.5 6.7 - 6.9 7.0 7.3 - 7.3 7.5 7.7 - 7.8 8.0 8.2 - 8.2 8.4 8.7 -
Hi PR 213 229 242 - 239 257 272 - 272 293 309 - 310 333 352 - 348 375 396 - 385 414 437 -
Lo PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 133 142 155 -
75
700
MBh 22.5 23.2 25.1 26.9 22.0 22.6 24.5 26.3 21.4 22.1 23.9 25.6 20.9 21.5 23.3 25.0 19.9 20.5 22.1 23.8 18.4 19.0 20.5 22.0
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
∆T 23 21 18 12 24 22 18 12 24 22 18 12 24 22 18 12 23 22 18 12 22 20 16 11
kW 1.55 1.58 1.62 1.67 1.66 1.69 1.74 1.79 1.75 1.78 1.84 1.89 1.83 1.87 1.93 1.99 1.90 1.94 2.00 2.06 1.96 2.00 2.07 2.13
Amps 5.7 5.9 6.1 6.3 6.2 6.3 6.5 6.8 6.7 6.9 7.1 7.3 7.2 7.3 7.6 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
Hi PR 207 223 236 246 233 250 264 276 265 285 301 314 301 324 343 357 339 365 385 402 375 403 426 444
Lo PR 104 111 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161
750
MBh 22.8 23.5 25.4 27.3 22.3 23.0 24.9 26.7 21.8 22.4 24.3 26.0 21.2 21.9 23.7 25.4 20.2 20.8 22.5 24.1 18.7 19.2 20.8 22.4
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
∆T 23 21 17 12 23 21 17 12
23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11
kW 1.57 1.60 1.64 1.69 1.68 1.71 1.76 1.81 1.77 1.81 1.86 1.92 1.86 1.89 1.95 2.01 1.93 1.97 2.03 2.09 1.99 2.03 2.09 2.16
Amps
5.8 6.0 6.1 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.5 7.3 7.4 7.7 8.0 7.7 7.9 8.2 8.5 8.2 8.4 8.6 9.0
Hi PR 211 227 240 250 237 255 269 281 269 290 306 319 307 330 348 363 345 371 392 409 381 410 433 452
Lo PR 106 112 123 131 112 119 130 138 116 123 135 144 122 130 142 151 128 136 148 158 132 141 153 163
900
MBh 23.6 24.3 26.3 28.3 23.1 23.8 25.7 27.6 22.5 23.2 25.1 27.0 22.0 22.6 24.5 26.3 20.9 21.5 23.3 25.0 19.3 19.9 21.6 23.1
S/T 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.83 0.62 0.40 0.95 0.85 0.64 0.41 0.99 0.88 0.67 0.43 1.00 0.89 0.67 0.43
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.59 1.62 1.67 1.72 1.70 1.73 1.79 1.84 1.80 1.83 1.89 1.95 1.88 1.92 1.98 2.04 1.96 2.00 2.06 2.12 2.02 2.06 2.13 2.19
Amps 5.9 6.1 6.3 6.5 6.4 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.6 7.8 8.1 7.9 8.0 8.3 8.6 8.3 8.5 8.8 9.1
Hi PR 215 232 245 255 241 260 274 286 275 296 312 326 313 337 355 371 352 379 400 417 389 418 442 461
Lo PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and sucon service valves. kW = Total system power
