16 www.goodmanmfg.com SS-GSX16
SS-GSX16 www.goodmanmfg.com 17
Product SPecificationS
Product SPecificationS
EXpAndEd coolinG dAtA — GSX160601f* / cA*f4961*6d*+tXV
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1750
MBh 51.9 53.8 58.9 - 50.7 52.5 57.6 - 49.5 51.3 56.2 - 48.3 50.0 54.8 - 45.9 47.5 52.1 - 42.5 44.0 48.2 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 20 18 13 - 20 18 13 - 21 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
kW 3.55 3.62 3.73 - 3.80 3.88 3.99 - 4.03 4.11 4.23 - 4.22 4.31 4.44 - 4.39 4.48 4.62 - 4.53 4.63 4.77 -
Amps 13.2 13.5 14.0 - 14.3 14.6 15.1 - 15.5 15.9 16.4 - 16.6 17.0 17.5 - 17.6 18.0 18.6 - 18.6 19.1 19.7 -
Hi PR 217 233 246 - 243 262 276 - 276 297 314 - 315 339 358 - 354 381 403 - 391 421 445 -
Lo PR 103 109 119 - 109 115 126 - 113 120 131 - 118 126 138 - 124 132 144 - 128 137 149 -
1625
MBh 51.4 53.2 58.3 - 50.2 52.0 57.0 - 49.0 50.8 55.6 - 47.8 49.5 54.3 - 45.4 47.1 51.6 - 42.1 43.6 47.8 -
S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -
∆T 21 18 14 - 21 19 14 - 21 19 14 - 22 19 14 - 21 18 14 - 20 17 13 -
kW 3.55 3.61 3.72 - 3.80 3.87 3.99 - 4.02 4.10 4.22 - 4.21 4.30 4.43 - 4.38 4.47 4.61 - 4.52 4.61 4.76 -
Amps 13.2 13.5 13.9 - 14.2 14.6 15.1 - 15.5 15.8 16.3 - 16.5 16.9 17.5 - 17.6 18.0 18.6 - 18.6 19.0 19.7 -
Hi PR 216 232 245 - 242 261 275 - 276 297 313 - 314 338 357 - 353 380 401 - 390 420 443 -
Lo PR 102 109 119 - 108 115 126 - 112 120 131 - 118 126 137 - 124 132 144 - 128 136 149 -
2250
MBh 53.2 55.1 60.4 - 51.9 53.8 59.0 - 50.7 52.5 57.6
- 49.5 51.3 56.2 - 47.0 48.7 53.4 - 43.5 45.1 49.4 -
S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.74 0.51 - 0.89 0.74 0.51 -
∆T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
kW 3.60 3.67 3.77 - 3.85 3.93 4.05 - 4.08 4.16 4.29 - 4.28 4.36 4.50 - 4.44 4.54 4.68 - 4.59 4.69 4.83 -
Amps
13.4 13.7 14.2 - 14.5 14.8 15.3 - 15.7 16.1 16.6 - 16.8 17.2 17.8 - 17.9 18.3 18.9 - 18.9 19.4 20.0 -
Hi PR 220 237 250 - 247 266 281 - 281 303 319 - 320 345 364 - 360 388 409 - 398 428 452 -
Lo PR 104 111 121 - 110 117 128 - 115 122 133 - 120 128 140 - 126 134 147 - 131 139 152 -
75
1750
MBh 52.8 54.3 58.8 63.1 51.5 53.1 57.4 61.6 50.3 51.8 56.1 60.2 49.1 50.5 54.7 58.7 46.6 48.0 52.0 55.8 43.2 44.5 48.1 51.7
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 23 22 18 12 24 22 18 12 24 22 18 12 24 22 18 12 24 22 18 12 22 20 17 11
kW 3.58 3.65 3.76 3.87 3.83 3.91 4.03 4.15 4.06 4.14 4.26 4.40 4.25 4.34 4.48 4.62 4.42 4.51 4.65 4.80 4.57 4.66 4.81 4.96
Amps 13.4 13.7 14.1 14.6 14.4 14.8 15.2 15.8 15.6 16.0 16.5 17.2 16.7 17.1 17.7 18.3 17.8 18.2 18.8 19.5 18.8 19.3 19.9 20.7
Hi PR 219 235 249 259 246 264 279 291 279 301 317 331 318 342 361 377 358 385 407 424 395 425 449 469
Lo PR 104 110 121 128 110 117 127 136 114 121 132 141 120 127 139 148 125 133 146 155 130 138 151 160
1625
MBh 52.2 53.8 58.2 62.5 51.0 52.5 56.9 61.0 49.8 51.3 55.5 59.6 48.6 50.0 54.2 58.1 46.2 47.5 51.5 55.2 42.8 44.0 47.7 51.2
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
∆T 24 23 18 13 25 23 19 13
25 23 19 13 25 23 19 13 25 23 19 13 23 21 17 12
kW 3.57 3.64 3.75 3.86 3.82 3.90 4.02 4.14 4.05 4.13 4.25 4.39 4.24 4.33 4.46 4.60 4.41 4.50 4.64 4.79 4.56 4.65 4.80 4.95
Amps
13.3 13.6 14.1 14.6 14.4 14.7 15.2 15.8 15.6 16.0 16.5 17.1 16.7 17.1 17.6 18.3 17.7 18.2 18.8 19.5 18.8 19.2 19.9 20.6
Hi PR 218 235 248 259 245 263 278 290 278 300 316 330 317 341 360 376 357 384 405 423 394 424 448 467
Lo PR 103 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160
2250
MBh 54.1 55.7 60.3 64.7 52.8 54.4 58.9 63.2 51.6 53.1 57.5 61.7 50.3 51.8 56.1 60.2 47.8 49.2 53.3 57.2 44.3 45.6 49.3 52.9
S/T 0.88 0.79 0.60 0.38 0.91 0.82 0.62 0.40 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.90 0.68 0.44 1.00 0.90 0.68 0.44
∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 18 17 14 10
kW 3.62 3.69 3.80 3.92 3.88 3.96 4.08 4.20 4.11 4.19 4.32 4.45 4.31 4.40 4.53 4.68 4.48 4.57 4.72 4.87 4.63 4.73 4.87 5.03
Amps 13.6 13.9 14.3 14.8 14.6 15.0 15.5 16.0 15.9 16.3 16.8 17.4 17.0 17.4 17.9 18.6 18.0 18.5 19.1 19.8 19.1 19.6 20.2 21.0
Hi PR 223 239 253 264 250 269 284 296 284 306 323 337 323 348 368 383 364 392 414 431 402 433 457 477
Lo PR 106 112 123 131 111 119 129 138 116 123 135 143 122 129 141 151 128 136 148 158 132 140 153 163
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and sucon service valves. kW = Total system power
