PRODUCT SPECIFICATIONS
Model CFM Wet Coil
Electric
Heat
Medium EFF.
Filters
Economizer Return
Air Damper
PCC090-X
2,600 0.06 0.03 0.03 0.14
3,000 0.06 0.04 0.04 0.14
3,400 0.07 0.05 0.05 0.18
PCC120-X
3,600 0.05 0.05 0.03 0.14
4,000 0.05 0.06 0.04 0.14
4,400 0.05 0.08 0.04 0.14
AMB. ˚F
EVAP.
EAT
75 ˚F DB 80 ˚F DB 85˚F DB 90 ˚F DB
KW MBHT MBHS KW MBHT MBHS KW MBHT MBHS KW MBHT MBHS
85
61 WB 7.6 83.8 72.1 7.6 85.7 84.8 7.7 90.6 90.6 7.7 95.5 95.5
64 WB 7.7 88.7 63.3 7.7 88.7 77.9 7.7 90.6 90.6 7.7 95.5 95.5
67 WB 7.7 94.5 54.6 7.7 94.5 69.2 7.7 94.5 82.8 7.8 95.5 95.5
70 WB 7.8 100.3 45.8 7.8 100.3 60.4 7.8 100.3 74.0 7.8 100.3 88.7
73 WB 7.8 106.2 37.0 7.8 106.2 51.6 7.8 106.2 65.3 7.9 106.2 79.9
90
61 WB 7.8 81.8 71.1 7.9 83.8 83.8 8.0 88.7 88.7 8.0 94.5 94.5
64 WB 8.0 86.7 62.4 8.0 87.7 77.0 8.0 88.7 88.7 8.0 94.5 94.5
67 WB 8.1 92.5 53.6 8.1 92.5 68.2 8.1 92.5 82.8 8.1 94.5 94.5
70 WB 8.1 97.4 44.8 8.1 97.4 59.4 8.1 98.4 74.0 8.2 98.4 87.7
73 WB 8.2 103.3 36.0 8.2 103.3 50.7 8.2 105.2 64.3 8.4 103.3 78.9
95
61 WB 8.2 80.9 71.1 8.3 82.8 82.8 8.3 87.7 87.7 8.4 93.5 93.5
64 WB 8.3 85.7 62.4 8.3 85.7 76.0 8.3 87.7 87.7 8.4 93.5 93.5
67 WB 8.4 90.6 53.6 8.4 90.6 68.2 8.4 90.6 81.8 8.4 93.5 93.5
70 WB 8.4 96.4 44.8 8.4 96.4 58.5 8.4 96.4 73.1 8.4 96.4 87.7
73 WB 8.5 101.3 35.1 8.5 101.3 49.7 8.5 101.3 64.3 8.6 101.3 78.9
100
61 WB 8.5 78.9 70.1 8.6 80.9 80.9 8.6 86.7 86.7 8.7 91.6 91.6
64 WB 8.6 83.8 61.4 8.6 83.8 76.0 8.6 86.7 86.7 8.7 91.6 91.6
67 WB 8.7 88.7 52.6 8.7 88.7 67.2 8.7 88.7 80.9 8.7 91.6 91.6
70 WB 8.8 94.5 43.8 8.8 94.5 58.5 8.8 94.5 72.1 8.8 94.5 85.7
73 WB 8.9 99.4 35.1 9.0 99.4 48.7 9.0 99.4 63.3 9.0 99.4 77.9
105
61 WB 8.9 77.0 69.2 8.9 79.9 79.9 9.0 84.8 84.8 9.1 89.6 89.6
64 WB 8.9 81.8 60.4 8.9 81.8 75.0 9.0 84.8 84.8 9.1 89.6 89.6
67 WB 9.1 86.7 51.6 9.1 86.7 66.3 9.1 86.7 79.9 9.1 89.6 89.6
70 WB 9.1 91.6 42.9 9.1 91.6 57.5 9.2 92.5 71.1 9.2 92.5 85.7
73 WB 9.4 98.4 34.1 9.4 98.4 48.7 9.4 98.4 62.4 9.4 98.4 77.0
COOLING CAPACITY DATA — PCC090-X @ 3,000 CFM
COMPONENT PRESSURE DROPS
NOTES:
1 Capacities are gross and are based on 230, 460 operation. 208-volt
operation must be derated by 0.98. Gross capacities do not include
evaporator motor heat.
AMB
EAT
DB
Ambient Air Temperature
Entering Air Temperature
Evaporator Dry Bulb EAT
2 kW is for entire unit WB Evaporator Wet Bulb EAT
3 See table for capacity correction factors at other than nominal CFM. CFM Evaporator Airfl ow Ft.³/min (Table 9a)
kW 1,000 Watts
SHADED AREA REPRESENTS 100% SENSIBLE COOLING MBHT 1,000 BTU/h Total Cooling
MBHS 00 BTU/h Sensible Cooling
