PRODUCT SPECIFICATIONS
SS-GPCC www.goodmanmfg.com 4/09
Supersedes 6/08
PACKAGED AIR CONDITIONER
The PCC Commercial packaged air conditioner
features combination electric heat/electric cooling
with dual high-e ciency scroll compressors. This unit
contains totally enclosed, permanently lubricated
outdoor fan motors and is designed for over/under or
down ow applications.
Standard Features
• Dual high-e ciency scroll compressors with internal
motor protection for 2-stage cooling
• Totally enclosed, permanently lubricated outdoor fan
motors
• Enhanced copper tube/aluminum n coils
• Fully charged R-22 systems
• Belt-driven, variable-pitch sheave permits multi-
speed adjustment
• Expansion valve evaporator coil
• Time delay for compressors sequence
• Compressor grommets for vibration isolation
• Two independent condenser coils for two-stage operation
• High- and low-pressure controls on all systems
• Mild ambient switch
• Centrifugal fan for quiet and e cient operation
Cabinet Features
• Heavy-gauge, zinc-coated steel cabinet with weather-
resistant powder-paint nish
• Fully insulated with blankets of insulation
• Vertical discharge with removable grilles
• Control box and compressors easily accessible from
side access panels
• Base rails with fork slots for convenience
of handling and added rigidity
• Galvanized steel, powder-coated drain pan with ¾” NPT
condensate connection
• Factory wiring conveniently arranged to install accessories
• Filters are provided with unit (2” disposable)
• When properly anchored, meets the 2001 Florida
Building Code unit integrity requirements for
hurricane-type winds
PCC COMMERCIAL
COOLING CAPACITY: 86,000 - 116,000 BTU/H
10.3 EER
* Full warranty details available at www.goodmanmfg.com.
7½ TO 10 TON
