GETTING TO KNOW YOUR STEAM CLEANER
3
1. Steam Bottle (x2)
2. Steam Trigger
3. Concentrator Nozzle
(Non-Detachable)
4. Power On / Steam Ready Lights
5. Water Tank
6. Water Tank Filling Plug
Technical Specifications
Voltage: 120V., 60Hz.
Power: 1500 Watts
Water Capacity: 8 US Fl. Oz. (240 ml.)
7. Nylon Bristle Brushes (x2)
8. Squeegee Handle (x2)
9. Extended Concentrator (x2)
10. Scrubbing Pad Set (x2)
11. Scrubbing Pad Holder (x2)
12. Squeegee (x2)
13. Carrying Bag (x2)
14. Filler Flask
*Note: Illustrations may differ from actual unit.
Nylon Detail Brush
This is best for any task requiring
concentrated medium-pressure steam
with additional rubbing
action to loosen
embedded dirt such as
cleaning grout in between
the tiles, ceramic and
marble.
To use: Push the nylon detail brush onto
the end of the concentrator nozzle.
Extended Concentrator
The extended concentrator can be used
to clean under toilet bowl rims or in hard
to reach places.
To use
: Push the extended
concentrator onto the end
of the concentrator nozzle.
Squeegee
This attachment is very useful for
cleaning large windows, plastic material,
ceramic, tiled or marble surfaces.
To use
: Attach the squeegee to the
window squeegee handle. With the
steam cleaner, apply steam abundantly
to the surface and then remove excess
water and dirt with the wiping edge.
CAUTION: When cleaning
windows, always avoid
any sudden changes in
temperature to prevent
glass breakage or cracks.
NOTE: If using the steam cleaner with
the nozzle pointing downwards, you will
need to return the unit to an upright
position every now and again to enable
the tube inside the water tank to dip into
the water reservoir, thereby preserving
the flow of water to the heating element.
Scrubbing Pads & Holder
This attachment is very useful for
cleaning counters, ceramic, tiled or
marble surfaces.
To use
: Attach the scrubbing
pad holder onto the
concentrator nozzle. Then
press the scrubbing pad onto
the base of the scrubbing
pad holder and twist slightly.
This will help the scrubbing
pads stay on more securely.
OPERATING INSTRUCTIONS
6
Tips On How To Use Your
Steam Cleaner
Water
• Use tap water for all your cleaning
needs.
• If you live in an area with hard
water, use distilled water when
steaming light colored fabrics to
eliminate the possibility of hard
water stains.
IMPORTANT: Do NOT add cleaning
solutions, scented perfumes, oils or any
other chemicals to the water used in
this appliance. Use tap water or
distilled water if the tap water in your
area is very hard.
Efficient Work
• For vertical surfaces, wipe always
from the top down, in this way the
dirty water will not soil surfaces
already cleaned.
• Avoid changing brushes back and
forth while cleaning. Start with the
smallest brush to clean tight spots
and corners first.
• Wipe dirt as soon as possible,
otherwise it will dry and re-adhere
to the surface.
CAUTION: This appliance must be
unplugged from the electrical outlet
before performing any cleaning or
maintenance tasks on the unit.
• Let the appliance cool down
completely before cleaning or
storing.
• Empty all water from the water
tank after each use.
• Store in a dry, cool place with the
filling hole open.
• A periodic rinse of your steam
cleaner will free it from deposits.
This is recommended every 10
tankfulls to free up any scale
deposits. Fill the water tank with
water and shake vigorously. Tilt
the cleaner upside down to empty
the water tank and any scale
deposits.
Care & Maintenance
Scrubbing
Pad Holder
Scrubbing Pads
