KEY PAD FUNCTIONS
POWER SWITCH:Turns unit ON/OFF
MODE: Allows you to scroll through and select
desired operating mode.
FAN: Select from three different fan settings;
High, Medium, and Low.
AUTO-TIMER
AUTO-TIMER Adjust:
Auto off- With machine in running mode, press timer
button to set timer control. Press or buttons to
select number of hours you would like the unit to run
before it automatically shuts off.
Auto on- With machine in stand by mode, press timer
button to set timer control. Press or buttons to
select number of hours before the unit automatically
starts running in air conditionning mode.
NOTE: The time is adjustable between 1-24 hours.
TEMPERATURE Adjust:
• Used for adjusting the thermostat.
• The default display is room temperature.
• In cooling mode, when button is pressed,
the set temperature is displayed and may be adjusted.
After 15 seconds the display will revert back to room
temperature. Temperature is only adjustable in cool
mode.
Timer & Temp. Display
Room Temp.
Temp. Set
Timer Set
MODE INDICATOR LIGHTS
Cooling Mode
When cool mode is selected, the indicator light will
shine GREEN. During the cooling mode, the air is
cooled and hot air is exhausted outside through the
exhaust tube. Adjust fan speed to suit your desired
comfort level.
Note: The air exchange h ose must vent outside the
room when using cool mode.
Dehumidify Mode
When dehumidify mode is selected, the indicator
light will shine ORANGE. Air is dehumidified as it
passes through the unit, without being in full
cooling mode. The fan will operate on med. speed.
If room temperature is >25°C (77°F), fan speed can
be adjusted; otherwise fan speed is fixed to “low”.
Note: The warm air exchange hose must vent inside
the room when using Dehumidify Mode, not outside
as it does when cooling. If the unit is vented outside,
some cooling will occur.
Fan Mode
When fan mode is selected, the indicator will shine
YELLOW. Air is circulated throughout the room
with no cooling.
Note: The unit does not need to be vented in Fan
mode.
• During Fan/Dehumidifier mode, the temperature
cannot be set.
FAN SPEED INDICATOR LIGHTS
High Fan
Medium Fan
Low Fan
NOTE: By pressing both buttons at the
same time for more than 3 seconds, the display will
toggle between Celsius and Fahrenheit.
STATUS DISPLAY
Warning Light
Condensed water may accumulate in the unit. If the
internal tank becomes full, the Warning signal in the
LCD Display will light up and the unit will not operate
until the unit has been drained.
NOTE: AFTER SWITCHING THE AIR CONDITIONER OFF, YOU MUST WAIT 3 MINUTES
BEFORE SWITCHING IT BACK ON AGAIN.
6
OPERATING INSTRUCTIONS
FEATURES
OF THE
CONTROL
PANEL
