Amcor PCMB-12000EH Air Conditioner User Manual



Always unplug the unit from the wall before performing any maintenance.
Make sure the unit is drained before moving.
Cleaning the Unit:
Only use a soft damp cloth.
Never use chemicals, oil-based products, detergents, or other cleaning solutions.
These could damage the cabinet.
Cleaning the “Upper” Filter:
Slide out the filter holder
from the unit.
Separate the filter fixer from
the filter holder (see fig. 1).
Remove the active carbon filter (black) and slide out the 3M™ High Air Flow filter (white).
To clean filters, vacuum with standard vacuum cleaner.
Insert the active carbon filter into the filter holder (see fig. 2).
Insert the 3M™ High Air Flow filter into the filter holder (see fig. 3).
Fix the filters by reassembling the fixer into the filter holder (see fig. 4).
Cleaning the “Lower” Filter:
Vacuum with standard vacuum cleaner.
NOTE:
Before storage be sure filters are clean and dry.
Should you need to replace filters, contact Amcor for replacement.
The screen filter must always be used.
The 3M™ High Air Flow filter should be cleaned periodically. Both filters can be vacuumed.
IMPORTANT: NEVER operate the unit without a filter.
End of Season Storage:
Unplug the unit.
Drain the condensed water COMPLETELY.
Clean the upper and lower filter.
Maintenance
14
