22 Unimode 400 Operations PN 50709:A 10/20/97
Annunciator Display
Selections
Press <Z>, <S1>, <Enter> to display Annunciator Selection 1 Screen which typically
displays as shown in Figure 23:
Figure 23 Annunciator Selection 1 Screen
Note: Refer to Appendix A,
Annunciators in the
Unimode400 Installation
Manual for detailed instructions
on using an AMG-1 in ACS
mode. For programming
instructions, refer to the
Unimode400 Programming
Manual.
If UDACT=N, the control panel displays the Annunciator Selection 2 Screen, addresses
A11–A19, as shown in Figure 24:
Figure 24 Annunciator Selection 2 Screen
Use the Annunciator Selection screen to select information that will display on the ACS
annunciators. Table 16 contains the ACS display selections.
Table 16 ACS Selection Groups
Example of Annunciator
Display Selections
Figure 25 shows an example of ACS selections in Annunciator Selection Screen 1:
Figure 25 Annunciator Selection Screen 1 Example
Figure 25 shows annunciator selections for addresses A1-A3 (addresses A4-A10 are
not selected).
• Annunciators set to Address 1 display the status of detectors 1-64 on SLC 1 (ACS
Selection Group 6);
• Annunciators set to Address 2 display the status intelligent modules 101-164 (ACS
Selection Group 3); and
• Annunciators set to Address 3 display the status of the panel modules (ACS
Selection Group 9).
ANNUN SELECTION1: A1=* A2=* A3=* A4=*
A5=* A6=* A7=* A8=* A9=* A10=* UDACT=N
A=Address
ACS Selection
Group
Annunciator Display
1 CPU status and zones 1-56
2 Zones 57 to 99, NAC circuits 1-4 and 16 special zones
3 Intelligent modules 101 to 164
4 Intelligent modules 201 to 264
5 Intelligent modules 165 to 196 and 265 to 296
6 Detectors 101 to 164 on SLC 1
7 Detectors 201 to 264 on SLC 2
8 Detectors 165 to 196 and 265 to 296
9 NAC/panel output circuit modules (64 points)
* or 0 Annunciator not installed at address
ANNUN SELECTION2: A11=* A12=* A13=*
A14=* A15=* A16=* A17=* A18=* A19=*
ANNUN SELECTION1: A1=6 A2=3 A3=9 A4=*
A5=* A6=* A7=* A8=* A9=* A10=* UDACT=Y
