Releasing Functions 3. Operating Modes
Unimode 400 Operations PN 50709:A 10/20/97 9
Using Cross Zoning Options Cross Zoning lets you program the control panel to
activate a releasing zone after two initiating devices are tripped. (If not using Cross
Zoning, set CROSS= to N.) Table 5 contains a summary of the types of cross zoning
and the conditions for activating a releasing zone.
Table 5 Cross Zoning Types
Note: Only the first non-special
zone listed in the zone map is
used to determine Cross=Z.
Cross Zoning Example Table 6 lists examples of devices mapped to releasing zones
(ZR1 stands for Releasing Zone 1).
Table 6 Devices Mapped to Releasing Zones
The following explanations apply to the examples listed in Table 6:
•
Cross=N An alarm from any detector activates the releasing circuit.
•
Cross=Y An alarm from any two detectors activates the releasing circuit.
•
Cross=Z Release requires the activation of two detectors mapped to different
zones: D101 and D102 cannot activate the releasing circuit because both detectors
are mapped to Z01; D101 and D103 can activate the releasing circuit because they
are mapped to different zones.
•
Cross=H Release requires activation of heat detector D104 and one smoke
detector (D101, D102, or D103).
Type Activates when...
Y Two or more detectors, all mapped to one of the ten releasing zones (R0-R9), are
tripped.
Z Two or more detectors, mapped to two different software zones and one of the ten
releasing zones (R0-R9), are tripped.
H At least one smoke detector and at least one heat detector, all mapped to one of the
ten releasing zones (R0-R9), are tripped.
Device Address Device Type Zone Mapping
D101 Detector Smoke ZR1 Z01
D102 Detector Smoke ZR1 Z01
D103 Detector Smoke ZR1 Z02
D104 Detector Heat ZR1 Z02
B01 Output Circuit (Rel Ckt) ZR1
