ENGLISH
TECHNICAL SPECIFICATION: EVEREST MULTI INVERTER “YUKC-RRJC” 50Hz
Indoor Unit Duct Type YUKC 07-18
Model YUKC 07AA-AAR YUKC 09AA-AAR YUKC 12AA-AAR YUKC 18AA-AAR
Power supply Ph-V-Hz 1Ph, 220-240V~, 50Hz 1Ph, 220-240V~, 50Hz 1Ph, 220-240V~, 50Hz
1Ph, 220-240V~, 50Hz
Capacity
Cooling Capacity
BTU/h 7,000 9,000 12,000 18,000
Heating Capacity
BTU/h 8,000 11,000 14,000 21,000
Power input w 40 40 40 65
Indoor fan
motor
Input W 38 38 38 63
Capacitor µF 1.0µF/450V 1.0µF/450V 1.0µF/450V 2.5µF/450V
Speed (Hi/Mi/Lo) r/min 735/650/560 735/650/560 735/650/560 930/830/660
Indoor coil
Number of rows 2 2 2 2
Fin spacing mm 1.5 1.5 1.5 1.7
Fin type Hydrophilic aluminium
Tube outside dia.
mm Ø7 Ø7 Ø7 Ø9.53
Tube Material Innergroove tube
Coil length x height
x width
mm 700x26x350 700x26x350 700x26x350 800x254x44
Number of circuits 4 4 4 3
Indoor air flow (Hi/Mi/Lo) m
3
/h 480/410/360 480/410/360 580/480/400 660/550/480
Indoor noise level (Hi/Mi/Lo) dB(A) 35/32/30 36/33/30 38/35/33 40/38/35
Pipe size Liquid side/ Gas side mm Ø6.35/Ø9.53 Ø6.35/Ø9.53 Ø6.35/Ø12.7 Ø6.35/Ø12.7
Indoor unit
Dimension (W*H*D) mm 955×210×385 955×210×385 955×210×385 1,301X210X385
Packing (W*H*D) mm 1,114x277x469 1,114x277x469 1,114x277x469 1,114x277x469
Net/Gross weight Kg 15/19 15/19 15/19 18/22
