P QX Y
(E)
Y/G
220-240V (3-core cable 3x2.5mm )
2
220-240V (3-core cable 3x1.0mm )
2
3-core sheild cable
INDOOR UNIT
L N
Power supply
Power suppl
y
For 18,000-24,000 Btu/h
1-Phase
1-Phas
e
380-415V (5-core cable 5x2.5mm )
2
3-core sheild cable
OUTDOOR UNIT
Power supply
3-Phase
220-240V (3-core cable 3x2.5mm )
2
Power supply
1-Phase
L3 NL2L1
For 36,000-60,000 Btu/h
DC Inverter R-410A
