FORM 150.63-EG1
NOTES:
1. For lower or higher suction temperature applications, contact your nearest YORK Ofce for application requirements.
2. For operation at temperatures below 25°F (-3.9°C), the optional Low Ambient Kit will need to be installed on the system (For YCUL0016
- 0090 models only).
3. For operation at temperatures above 115°F (46.1°C), the optional High Ambient Kit will need to be installed on the system.
ENGLISH UNITS
Design Parameters
YCUL
SUCTION
TEMPERATURE (°F)
AIR ON
CONDENSER (°F)
MIN
1
MAX
1
MIN
2
MAX
3
0016 35 55 0 125
0026 35 55 0 125
0030 35 55 0 125
0036 35 55 0 125
0040 35 55 0 125
0046 35 55 0 125
0050 35 55 0 125
0056 35 55 0 125
0060 35 55 0 125
0066 35 55 0 125
0076 35 55 0 125
0080 35 55 0 125
0086 35 55 0 125
0090 35 55 0 125
0096 35 55 0 125
0100 35 55 0 125
0106 35 55 0 125
0120 35 55 0 125
0130 35 55 0 125
