528150-YTG-G-1210
94 Johnson Controls Unitary Products
ZR150 (12.5 Ton) Reheat
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
85 80 75 70 65 85 80 75 70 65
35°F 45°F
3125
72 87.0 7.7 6.6 4.8 3.1 - - 85.9 8.3 5.6 3.9 2.2 - -
67 84.6 7.3 14.4 12.7 11.0 9.2 - 83.3 8.0 11.8 10.1 8.4 6.7 -
62 82.9 7.3 20.3 18.6 16.9 15.2 13.5 80.8 7.7 17.7 16.0 14.3 12.6 10.9
3750
72 89.0 7.4 11.5 9.2 6.9 - - 88.9 8.0 10.7 8.3 5.9 - -
67 86.5 7.1 26.3 24.0 21.7 19.5 - 86.2 7.7 24.1 21.7 19.3 17.0 -
62 84.8 7.1 36.7 34.4 32.1 29.8 27.5 83.6 7.4 36.6 34.2 31.9 29.5 27.1
57 82.2 7.7 43.1 40.9 38.6 36.3 34.0 79.1 8.2 40.8 38.4 36.0 33.7 31.3
4375
72 90.9 7.2 16.4 13.5 10.7 - - 91.8 7.7 15.8 12.7 9.7 - -
67 88.4 6.9 38.3 35.4 32.5 29.7 - 89.1 7.4 36.3 33.3 30.2 27.2 -
62 86.6 6.8 53.1 50.2 47.4 44.5 41.6 86.4 7.2 55.5 52.5 49.4 46.4 43.3
57 84.0 7.4 63.2 60.0 57.1 54.2 51.4 81.8 7.9 61.9 58.9 55.8 52.8 49.7
5000
72 92.8 6.9 21.3 17.9 14.4 - - 94.8 7.4 20.9 17.2 13.4 - -
67 90.3 6.6 50.2 46.8 43.3 39.9 - 91.9 7.1 48.6 44.9 41.1 37.4 -
62 88.5 6.6 69.5 66.0 62.6 59.1 55.7 89.2 6.9 74.5 70.7 67.0 63.3 59.5
57 85.9 7.1 83.2 79.1 75.6 72.2 68.7 84.4 7.6 83.1 79.4 75.6 71.9 68.2
5625
72 94.1 7.5 15.2 12.5 9.9 - - 96.7 7.8 16.3 13.1 9.9 - -
67 91.5 7.1 35.5 32.8 30.2 27.5 - 93.8 7.6 37.4 34.2 31.0 27.8 -
62 89.7 7.1 48.0 45.4 42.7 40.1 37.4 91.0 7.3 57.1 53.9 50.7 47.5 44.3
57 87.1 7.7 58.0 55.0 52.4 49.7 47.1 86.1 8.0 63.7 60.5 57.3 54.1 50.8
6250
72 95.4 8.0 9.1 7.2 5.4 - - 98.6 8.3 11.7 9.0 6.3 - -
67 92.8 7.7 20.7 18.9 17.0 15.2 - 95.6 8.0 26.2 23.5 20.8 18.1 -
62 91.0 7.6 26.6 24.7 22.9 21.0 19.2 92.8 7.8 39.8 37.1 34.4 31.7 29.0
57 88.3 8.3 32.9 31.0 29.2 27.3 25.5 87.8 8.5 44.3 41.6 38.9 36.2 33.5
55°F 65°F
3125
72 84.8 8.94.62.91.2-- 84.2 9.3 -----
67 81.9 8.7 9.3 7.6 5.9 4.2 - 79.1 8.9 10.4 8.9 7.3 5.8 -
62 78.7 8.2 15.1 13.4 11.7 10.0 8.3 74.6 8.4 24.9 23.4 21.8 20.3 18.7
3750
72 88.8 8.69.97.45.0-- 87.3 9.2 -----
67 85.8 8.3 21.9 19.4 16.9 14.5 - 82.0 8.8 18.2 16.0 13.9 11.8 -
62 82.5 7.8 36.5 34.1 31.6 29.1 26.7 77.4 8.3 40.0 37.9 35.8 33.7 31.5
57 76.1 8.7 38.4 36.0 33.5 31.0 28.6 72.6 9.0 44.1 42.0 39.9 37.8 35.6
4375
72 92.8 8.215.211.98.7-- 90.4 9.1 -----
67 89.7 8.0 34.4 31.2 27.9 24.7 - 85.0 8.7 25.9 23.2 20.5 17.8 -
62 86.2 7.5 58.0 54.7 51.5 48.3 45.0 80.2 8.2 55.1 52.4 49.8 47.1 44.4
57 79.5 8.3 60.7 57.8 54.6 51.3 48.1 75.2 8.9 60.3 57.7 55.1 52.4 49.7
5000
72 96.8 7.8 20.5 16.5 12.4 - - 93.5 9.0 1.1 - - - -
67 93.6 7.6 47.0 42.9 38.9 34.9 - 87.9 8.6 33.6 30.4 27.1 23.8 -
62 89.9 7.1 79.4 75.4 71.4 67.4 63.4 83.0 8.1 70.3 67.0 63.7 60.4 57.2
57 83.0 8.0 83.0 79.6 75.6 71.6 67.6 77.8 8.8 76.4 73.5 70.2 66.9 63.7
5625
72 99.3 8.217.413.69.8-- 97.7 9.2 -----
67 96.0 8.0 39.3 35.5 31.8 28.0 - 91.8 8.8 31.7 28.3 25.0 21.6 -
62 92.2 7.5 66.2 62.4 58.7 54.9 51.1 86.6 8.3 69.4 66.0 62.6 59.3 55.9
57 85.1 8.4 69.3 65.9 62.1 58.4 54.6 81.2 9.0 72.7 70.3 66.9 63.6 60.2
6250
72101.8 8.614.310.87.3--101.9 9.5 -----
67 98.4 8.4 31.7 28.1 24.6 21.1 - 95.7 9.1 29.8 26.3 22.8 19.4 -
62 94.6 7.9 53.0 49.4 45.9 42.4 38.8 90.3 8.6 68.5 65.0 61.6 58.1 54.6
57 87.2 8.8 55.7 52.2 48.7 45.1 41.6 84.7 9.3 68.9 67.1 63.7 60.2 56.8
