528150-YTG-G-1210
Johnson Controls Unitary Products 47
ZH120 (10 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
2500
77 156.8 7.2 67.5 56.5 45.5 - - - 148.8 8.0 62.9 51.9 41.0 - - -
72 143.5 7.1 84.0 73.0 62.0 50.9 - - 136.5 8.0 80.1 69.2 58.3 47.3 - -
67 130.3 7.0 100.5 89.4 78.4 67.4 56.4 - 124.3 7.9 97.4 86.4 75.5 64.6 53.7 -
62 118.3 6.9 118.3 107.9 94.1 83.1 72.1 61.1 112.4 7.8 112.4 105.8 90.3 79.4 68.4 57.5
3000
77 162.2 7.2 75.3 62.4 49.6 - - - 153.1 8.1 70.1 57.4 44.8 - - -
72 148.5 7.1 93.2 80.4 67.5 54.7 - - 140.4 8.0 88.9 76.3 63.6 51.0 - -
67 134.8 7.0 111.2 98.3 85.5 72.7 59.8 - 127.8 7.9 107.8 95.1 82.5 69.8 57.2 -
62 122.4 6.9 122.4 115.5 102.6 89.8 76.9 64.1 115.6 7.9 115.6 111.2 98.6 85.9 73.3 60.6
57 110.3 7.0 110.3 110.6 114.0 101.2 88.4 75.5 111.0 7.9 111.0 111.0 106.5 93.9 81.2 68.6
3500
77 167.6 7.2 83.0 68.4 53.7 - - - 157.3 8.1 77.3 62.9 48.5 - - -
72 153.5 7.1 102.5 87.8 73.1 58.5 - - 144.3 8.0 97.7 83.3 69.0 54.6 - -
67 139.3 7.0 121.9 107.2 92.6 77.9 63.3 - 131.3 7.9 118.1 103.8 89.4 75.0 60.6 -
62 126.5 7.0 126.5 123.0 111.1 96.5 81.8 67.1 118.8 7.9 118.8 116.6 106.9 92.5 78.1 63.7
57 114.1 7.0 114.1 114.2 123.5 108.8 94.2 79.5 114.1 7.9 114.1 114.1 115.5 101.1 86.7 72.3
4000
77 173.0 7.2 90.8 74.3 57.8 - - - 161.6 8.1 84.5 68.4 52.3 - - -
72 158.4 7.1 111.7 95.2 78.7 62.3 - - 148.2 8.0 106.5 90.4 74.3 58.2 - -
67 143.8 7.0 132.6 116.1 99.7 83.2 66.7 - 134.9 8.0 128.5 112.4 96.3 80.2 64.1 -
62 130.6 7.0 130.6 130.6 119.6 103.1 86.6 70.2 122.0 7.9 122.0 122.0 115.2 99.1 83.0 66.8
57 117.9 7.0 117.9 117.9 132.9 116.4 100.0 83.5 117.2 7.9 117.2 117.2 124.4 108.3 92.2 76.1
4500
72 162.4 7.2 119.8 102.0 84.1 66.2 - - 151.6 8.1 114.4 96.9 79.4 61.8 - -
67 147.4 7.1 141.8 124.3 106.5 88.6 70.7 - 137.9 8.0 134.8 120.4 102.9 85.3 67.8 -
62 133.8 7.0 133.8 133.8 128.4 110.5 92.6 74.8 124.8 7.9 124.8 124.8 121.3 103.8 86.3 68.8
57 120.9 7.1 120.9 120.9 128.4 110.5 92.7 74.8 119.8 7.9 119.8 119.8 123.4 105.9 88.4 70.9
5000
72 166.4 7.2 127.9 108.7 89.5 70.2 - - 154.9 8.1 122.3 103.3 84.4 65.5 - -
67 151.0 7.1 151.0 132.5 113.3 94.0 74.8 - 141.0 8.0 141.0 128.3 109.4 90.5 71.5 -
62 137.1 7.0 137.1 137.1 137.1 117.9 98.6 79.4 127.5 7.9 127.5 127.5 127.5 108.6 89.6 70.7
57 123.8 7.1 123.8 123.8 123.8 104.6 85.4 66.1 122.5 7.9 122.5 122.5 122.5 103.5 84.6 65.7
95°F 105°F
2500
77 140.9 8.9 58.2 47.4 36.5 - - - 129.5 10.0 53.3 44.3 33.6 - - -
72 129.6 8.9 76.2 65.4 54.6 43.8 - - 120.0 10.0 72.8 62.1 51.4 40.8 - -
67 118.3 8.8 94.3 83.4 72.6 61.8 51.0 - 110.5 9.9 92.3 80.0 69.3 58.6 48.0 -
62 106.5 8.8 106.5 103.8 86.4 75.6 64.8 54.0 99.9 9.9 99.9 98.5 83.2 72.6 61.9 51.2
3000
77 143.9 9.0 64.9 52.4 40.0 - - - 132.3 10.1 61.4 49.1 36.8 - - -
72 132.4 8.9 84.6 72.1 59.7 47.2 - - 122.6 10.0 80.9 68.6 56.3 44.0 - -
67 120.8 8.8 104.3 91.9 79.4 67.0 54.5 - 112.9 10.0 100.5 88.2 75.9 63.6 51.3 -
62 108.8 8.8 108.8 107.0 94.5 82.1 69.6 57.2 102.0 9.9 102.0 101.1 91.1 78.8 66.5 54.2
57 111.7 8.7 111.7 111.4 99.0 86.5 74.1 61.6 104.8 9.9 104.8 104.6 93.2 80.9 68.6 56.3
3500
77 147.0 9.0 71.6 57.5 43.4 - - - 135.1 10.1 69.4 53.9 39.9 - - -
72 135.2 8.9 93.0 78.9 64.8 50.7 - - 125.2 10.0 89.0 75.1 61.2 47.3 - -
67 123.4 8.9 114.4 100.3 86.2 72.1 58.0 - 115.3 10.0 108.7 96.4 82.4 68.5 54.6 -
62 111.1 8.8 111.1 110.2 102.6 88.5 74.4 60.3 104.2 10.0 104.2 103.8 99.0 85.1 71.1 57.2
57 114.1 8.8 114.1 114.0 107.4 93.3 79.3 65.2 107.0 9.9 107.0 106.9 101.3 87.4 73.4 59.5
4000
77 150.1 9.0 78.2 62.5 46.8 - - - 137.9 10.1 77.4 58.7 43.1 - - -
72 138.0 9.0 101.3 85.6 69.9 54.2 - - 127.8 10.1 97.2 81.6 66.1 50.5 - -
67 126.0 8.9 124.4 108.7 93.0 77.3 61.6 - 117.7 10.0 116.9 104.5 89.0 73.4 57.9 -
62 113.4 8.9 113.4 113.4 110.7 95.0 79.3 63.5 106.4 10.0 106.4 106.4 106.9 91.3 75.8 60.2
57 116.5 8.8 116.5 116.5 115.9 100.2 84.5 68.7 109.2 9.9 109.2 109.2 109.4 93.8 78.3 62.7
4500
72 140.8 8.9 109.0 91.8 74.6 57.4 - - 129.8 10.1 104.4 87.5 70.6 53.7 - -
67 128.5 8.9 127.7 116.5 99.3 82.1 64.9 - 119.5 10.0 119.2 111.3 95.2 78.2 61.3 -
62 115.7 8.9 115.7 115.7 114.3 97.1 79.9 62.8 108.1 10.0 108.1 108.1 108.3 91.4 74.5 57.6
57 118.8 8.8 118.8 118.8 118.5 101.3 84.1 67.0 111.0 9.9 111.0 111.0 111.0 94.1 77.2 60.3
5000
72 143.5 8.9 116.6 98.0 79.3 60.7 - - 131.8 10.1 111.7 93.5 75.2 57.0 - -
67 131.0 8.9 131.0 124.2 105.6 86.9 68.3 - 121.4 10.0 121.4 118.0 101.3 83.1 64.8 -
62 117.9 8.8 117.9 117.9 117.9 99.3 80.6 62.0 109.8 10.0 109.8 109.8 109.8 91.5 73.2 55.0
57 121.1 8.8 121.1 121.1 121.1 102.5 83.8 65.2 112.7 9.9 112.7 112.7 112.7 94.4 76.2 57.9
