TABLE 1: PHYSICAL DATA
Component
Models
090 120 150
Evaporator
Blower
Blower, Centrifugal
Dia. X Wd. in.
(Dia. X Wd. mm.)
15 x 15
(381 x 381)
15 x 15
(381 x 381)
15 x 15
(381 x 381)
Motor, Standard - HP (kW) 1-1/2 (1.1) 2 (1.5) 4 (3)
Motor, Optional - HP (kW) 2 (1.5) 4 (3) N/A
Evaporator
Coil
Rows 2 3 4
Fins per 2.54 cm (1 in.) 15 15 15
Height - in. (mm.) 32 (810) 40 (1020) 40 (1020)
Face Area - ft.
2
(m
2
)
10.6 (0.98) 13.2 (1.23) 13.2 (1.23)
Condenser
Fan
(2 per Unit)
Propeller Dia. - in. (mm.) ea. 24 (610) 24 (610) 24 (610)
Motor - HP (kW) ea. 1/3 (0.25) 3/4 (0.56) 3/4 (0.56)
Airflow - CFM (m
3
/s) ea.
3700 (1.75) 3700 (1.75) 3700 (1.75)
Condenser
Coil
(2 per unit)
Rows (each) 1 1 2
Fins per inch (2.54 mm) 20 20 20
Height - in. (mm.) 28 (711) 44 (1120) 44 (1120)
Face Area - ft.
2
(m
2
)
9.2 (.86) 14.5 (1.35) 14.5 (1.35)
Refrigerant
Charge
System 1 - lbs. (kg.) 4.38 (1.99) 6.75 (3.06) 11.0 (4.99)
System 2 - lbs. (kg.) 4.13 (1.87) 6.13 (2.78) 10.0 (4.54)
Compressors
Quantity 2 2 2
Type Recip Recip Scroll
Air Filters
Size
Wd. x Ht. x Thickness in.
(Wd. x Ht. x Thickness mm.)
25 x 20 x 2
(635 x 508 x 51)
25 x 20 x 2
(635 x 508 x 51)
25 x 20 x 2
(635 x 508 x 51)
Number Per Unit 4 4 4
