036-21484-001-B-0103
Unitary Products 13
NOTE:
Electric heaters are rated at nominal voltage. Use this
table to determine the electric heat capacity for heaters sup-
plied at lower voltages.
NOTES FOR TABLES 12 AND TABLE 13:
• Blower performance includes dry coil and 2” throwaway
filters.
• Blower performance for gas heat includes the maximum
number of heat tubes available for each tonnage.
ESP (External Static Pressure) given is that available for the
supply and return air duct system. All internal resistances
have been deducted from the total static pressure of the
blower.
TABLE 10: DJ 150 (12-1/2 TON) - ELECTRICAL DATA
Model Compressors
OD Fan
Motors
Motor,
Supply
Blowe
FLA
Pwr
Exh
Motor
Electric Heater
Model
No.
Rated
kW
Minimum Circuit
Ampacity
Amps
MCA
with
Power
Exhaust Amps
Max Fuse
Size
* Amps
Max Fuse
Size
w/ Pwr. Exh. * Amps
Tonnage Voltage RLA each LRA each FLA each 3 HP 5 HP FLA 3 HP 5 HP 3 HP 5 HP 3 HP 5 HP 3 HP 5 HP
12 1/2
208 20.0 146 1.5 10.9 16.1 5.5
None - 61.9 67.1 67.4 72.6 80 80 80 90
2TP04511825 13.5 61.9 67.1 67.4 73.8 80 80 80 90
2TP04512425 18.0 76.1 82.6 83.0 89.5 80 90 90 90
2TP04513625 25.5 102.1 108.6 109.0 115.5 110 110 110 125
2TP04515425 40.6 154.5 161.0 161.4 167.9 175 175 175 175
230 20.0 146 1.5 10.9 16.1 5.5
None - 61.9 67.1 67.4 72.6 80 80 80 90
2TP04511825 18.0 67.8 74.3 74.6 81.1 80 80 80 90
2TP04512425 24.0 85.8 92.3 92.7 99.2 90 100 100 100
2TP04513625 34.0 115.9 122.4 122.7 129.2 125 125 125 150
2TP04515425 54.0 143.5 150.0 150.4 156.9 175 175 175 175
460 8.4 73 0.8 5.3 8.1 2.2
None - 27.4 30.2 29.6 32.4 35 35 35 40
2TP04511846 18.0 33.7 37.2 36.4 39.9 35 40 40 40
2TP04512446 24.0 42.7 46.2 45.5 49.0 45 50 50 50
2TP04513646 34.0 57.7 61.2 60.5 64.0 60 70 70 70
2TP04515446 54.0 71.6 75.1 74.3 77.8 80 90 80 90
575 6.7 60 0.6 4.1 6.0 1.8
None - 21.6 23.5 23.4 25.3 25 30 30 30
2TP04511858 18.0 26.8 29.2 29.0 31.4 30 30 30 35
2TP04512458 24.0 34.0 36.4 36.2 38.6 35 40 40 40
2TP04513658 34.0 46.0 48.4 48.3 50.6 50 50 50 60
2TP04515458 54.0 57.1 59.5 59.3 61.7 70 70 70 70
TABLE 11: ELECTRIC HEAT MULTIPLIERS
VOLTAGE
kW Cap. Multiplier
NOMINAL RATING
240
208 0.75
230 0.92
480 460 0.92
600 575 0.92
