GENERAL
YORK Model D1NA and D2NA units are cooling/heating air con
-
ditioners designed for outdoor installation. Only gas piping, elec
-
tric power and duct connections are required at the point of
installation.
The gas-fired heaters have hot surface to pilot ignition. The tu
-
bular heat exchangers are aluminized steel.
This appliance is not to beused for temporary heatingof build
-
ings or structures under construction.
INSPECTION
As soon as a unit is received, it should be inspected for possi
-
ble damage during transit. If damage is evident, the extent of
thedamage shouldbenotedon thecarrier'sfreight bill.Asepa-
rate request for inspection by the carrier's agent should be
made in writing. Refer to Form 50.15-NM for additional infor-
mation.
REPLACEMENT PARTS
• Refer to Replacement Parts, Form 530.46-RP1Y, RP2Y,
RP3Y, RP4Y and RP5Y for Key Replacement Parts.
All forms referenced in this instruction may be ordered from:
Standard Register
Norman, OK 73069
Toll Free: Tel. 877-318-9675/Fax. 877-379-7920
APPROVALS
Design certified by CGA and AGA listed as follows:
1. For use as a forced air furnace with cooling unit.
2. For outdoor installation only.
3. For installation directly on combustible flooring or, in U.S.,
on wood flooring or Class A; B; C roof covering material.
4. For installation on combustible material.
5. For use with natural gas and/or propane (LP) gas.
CHAMPION
®
SERIES
SINGLE PACKAGE AIR CONDITIONERS
GAS/ELECTRIC, AIR-COOLED
Supersedes: 035-18265-000-A-0801
035-18265-001-A-0202
INSTALLATION INSTRUCTION
Installer should pay particular attention to the words: NOTE, CAUTION and WARNING. Notes are intended to clarify or make
theinstallationeasier. Cautions
aregivento preventequipmentdamage.Warningsaregiven toalertinstallerthatpersonalinjury
and/or equipment damage may result if installation procedure is not handled properly.
®
CAUTION
THE ENCLOSED INSTALLATION INSTRUCTIONS AND ANY APPLICABLE
LOCAL, STATE, AND NATIONAL CODES INCLUDING, BUT NOT LIMITED
TO, BUILDING, ELECTRICAL, AND MECHANICAL CODES.
THIS PRODUCT MUST BE INSTALLED IN STRICT COMPLIANCE WITH
WARNING
OPERATION OF THE PRODUCT COULD CAUSE PERSONAL INJURY
OR PROPERTY DAMAGE.
INCORRECT INSTALLATION MAY CREATE A CONDITION WHERE THE
—
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
—
WHAT TO DO IF YOU SMELL GAS
·
Do not try to light any appliance.
·
Extinguish any open flames.
·
Do not touch any electrical switch; do
not use any phone in your building.
·
Immediately call your gas supplier from
aneighbor's phone. Follow the gas
supplier's instructions.
·
If you cannot reach your gas supplier,
call the fire department.
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
MODELS D1NA018 THRU 048
AND MODEL D2NA060
1-1/2 THRU 5 TON
(10 SEER)
