Note: This LCD image is shown
with all icons illuminated. Under
normal conditions, only select
icons will be lit.
Basic Operation
LCD Interface
3-Digit Display:Thisdisplayisgenerallyusedtoshowvaluesforagiven“Display”
or “Control” screen.
“ON/OFF” Button
• To turn the UPS ON:AfteryouplugtheUPSintoaliveACoutlet,theUPS(in
“Standby” mode) will automatically charge its batteries, but will not supply
powertoitsoutletsuntilitisturnedON.WiththeUPSpluggedintoaliveAC
walloutlet,pressandholdthe“ON/OFF”buttonforonesecond.*TheUPSwill
beeponcetoindicateONstatus.Releasethebutton.
• To cold-start the UPS:Ifutilitypowerisabsent,youcan“cold-start”theUPS
(i.e., turn it on and supply power for a limited time from its batteries) by pressing
andholdingthe“ON/OFF”buttonforonesecond.*TheUPSwillbeeponceto
indicateONstatus.Releasethebutton.
• To turn the UPS OFF:WiththeUPSONandreceivingutilitypower,pressand
holdthe“ON/OFF”buttonfor2.5seconds.*TheUPSwillbeeponcetoindicate
OFF status. Then unplug the UPS from the wall outlet. The UPS will be
completely off.
* If the user unintentionally presses the ON/OFF button, the OFF function can be temporarily
canceled by continuing to hold the ON/OFF button until the UPS beeps and then, without
releasing it, momentarily press either the MODE button or the ENTER/MUTE button. Once
both buttons are released, the UPS will remain ON.
“MODE” Button
To enable viewing of power displays and control menu options, tap this button. See
“DisplayPowerConditions”&“ControlMenuOptions”fordetails.
• Can be used in conjunction with the ON/OFF button to cancel the “OFF”
function.See“ON/OFFButton”instructionsabove.
• CanbeusedinconjunctionwiththeENTER/MUTEbuttontorestoretheLCDto
FactoryMode.See“ControlMenuOptions.”
