6. SETTING ON THE MENU SCREEN (Cont’d)
VIDEO LEVEL SCREEN (Cont’d)
Item
DETECT
AREA
It sets the detection area with the AUTO IRIS mode. Change this according to the
condition of use.
NORMAL
CIRCLE
SQUARE
RECTANGLE
FULL
Function and operation Variable values
NORMAL CIRCLE
RECTANGLE FULL
SQUARE
Detecting
area
Detecting
area
Detecting
area
Detecting
area
Detecting
area
WHITE BALANCE SCREEN
Item
COLOR TEMP The basic color temperature of the white balance can be set.
3200 K: For low color temperature light source such as a halogen lamp, etc.
5200 K: For a high color temperature light source such as the sun, etc.
WHITE
BALANCE
Different modes for the white balance can be set.
MANUAL
PRESET
AUTO
FAW
: White balance can be varied manually with the “PAINT R” adjust knob
or the “PAINT B” adjust knob.
: White balance is fixed to the setting value (3200 K or 5200 K) of the
“COLOR TEMP.” item.
: It is set to carry out the white balance adjustment.
Refer to the “WHITE BALANCE ADJUSTMENT” on page 13.
: The white balance trails automatically even when the lighting condition
is changed.
Refer to the “FULL TIME AUTO-WHITE FUNCTION” on page 14.
3200K
5200K
MANUAL
PRESET
AUTO
FAW
Function and operation Variable values
[Variable values of COLOR TEMP. and WHITE BALANCE]
COLOR
TEMP
WHITE
BALANCE
AUTO
FAW
MANUAL
PRESET
AUTO
FAW
MANUAL
PRESET
3200K
5200K
2000K 2500K 2800K 3200K 4500K 5200K 5600K 8000K
15000K
COLOR TEMPERATURE
