2 System Specifications
The following specifications are based on ASHRAE Class 1. Class 1 is a controlled computer
room environment, in which products are subject to controlled temperature and humidity
extremes. Throughout this chapter each specification is defined as thoroughly as possible to
ensure that all data is considered, to ensure a successful site preparation and system installation.
For more information, see Generalized Site Preparation Guide, Second Edition, part number
5991-5990, at the http://docs.hp.com website.
Dimensions and Weights
This section contains server component dimensions and weights for the system.
Component Dimensions
Table 2-1 lists the dimensions for the cabinet and components. Table 2-2 list the dimensions for
optional I/O expansion (IOX) cabinets.
Table 2-1 Server Component Dimensions
Maximum Quantity
per Cabinet
Height (in/cm)Depth (in/cm)Width (in/cm)Component
177.2/195.648/121.930/76.2Cabinet
8
1
3.0/7.620.0/50.216.5/41.9Cell board
8
1
3.0/7.610.125/25.716.5/41.9Cell power board (CPB)
117.6/44.711.0/27.9I/O backplane
11.5/3.823.75/60.33.25/8.3Master I/O backplane
48.38/21.317.5/44.412.0/30.5I/O card cage
29.75/24.311.0/27.97.5/19.0PDCA
1 SD16 is limited to a maximum of 4.
Table 2-2 I/O Expansion Cabinet Component Dimensions
Depth (in/cm)Width (in/cm)Height (in/cm)Cabinet Type
77.3/196.023.5/59.763.5/161E33
36.5/92.723.5/59.777.5/197E41
Component Weights
Table 2-3 lists the server and component weights. Table 2-4 lists the weights for optional IOX
cabinets.
NOTE: To determine the weight of the Support Management Station (SMS) and any console
used with this server, see the related documents.
Table 2-3 System Component Weights
Weight (lb/kg)QuantityWeight Per Unit
(lb/kg)
Component
745.17/338.101745.17/338.1Chassis
1
247.68/112.32830.96/14.04Cell board without power board and DIMMs
