036-21346-001 Rev. A (202)
Unitary Products Group 3
CAPACITY & PERFORMANCE DATA
UNIT MODEL
NUMBER
COOLING
CAPACITY 95°F
UNIT CHARGE
WEIGHT HCFC-22
RATED CFM
SENSIBLE
TOTAL RATIO
SOUND RATING
PAC036H1081A 33,000 3.7 Lbs. 1,200 0.74 8.4
PAC048H1081A 47,000 7.0 Lbs. 1,500 0.68 8.4
PAC060H1081A 55,000 7.6 Lbs. 1,600 0.65 8.4
BLOWER PERFORMANCE DATA
UNIT SPEED STATIC PRESSURE
PAC036H1081A
PAC048H1081A
PAC060H1081A
.1 .2 .3 .4 .5 .6 .7 .8
1837 1781 1720 1672 1607 1534 1443 1352 1243
1489 1468 1441 1412 1378 1336 1279 1204 1120
1238 1228 1216 1207 1180 1138 1088 1024 938
COMPRESSOR DATA
UNIT MODEL PAC036H1081A PAC048H1081A PAC060H1081A
MANUFACTURER
Bristol Bristol Bristol
COMPRESSOR MODEL H23A383DBEA H23A543DBEA H26A68QDBEA
RPM (50 Hz) 3,000 3,000 3,000
RATED LOAD AMPS 6.1 8.0 9.6
LOCK ROTOR AMPS 39.0 53.0 79.0
BRANCH CIRCUIT SELECTION
CURRENT (BCSC)
6.1 8.0 9.6
ELECTRICAL DATA - Packaged A/C (No Electric Heat)
MODEL
PAC036H1081A PAC048H1081A PAC060H1081A
Power Supply Volts / Phase / Hertz 380--415 / 3 / 50
Maximum Fuse Size (Amp) 15 20 20
Maximum Circuit Breaker Size (Amp) 15 20 25
Min. Wire Size (AWG) Copper (75_C) Size -- Ft.
#14--0--80
#12--81--130
#14--0--60
#12--61--90
#12--0--60
#10--61--100
Total Input @ Rated Conditions
Running Amps 7.4 10.2 11.3
Running Watts 4,050 5,870 6,650
CONDENSER COIL DATA
MODEL
PAC036H1081A PAC048H1081A PAC060H1081A
Face Area, Sq. Ft. 9.25 11.24 11.24
Tube Diameter Inches 3/8 3/8 3/8
Rows Deep 1 2 2
Fins / Inch 18 15 15
