331471-YTG-A-0507
14 Unitary Products Group
COIL - UC
B
C
A
DIMENSIONS - UC Coils
Model
Dimensions — Inches
Refrigerant
Connections
Model
Dimensions — Inches
Refrigerant
Connections
ABC
Line Size
ABC
Line Size
Liquid Vapor Liquid Vapor
UC18A3XN1
13
19.875
17
3/8
3/4
UC36C3XN1
19.5
19.875
22
3/8 7/8
UC18A2AN1 UC36C2AN1
UC18B3XN1
16 16.5
UC42B3XN1
16 26.5
UC18B2AN1 UC42B2CN1
UC24A3XN1
13 21
UC42C3XN1
19.5 25.5
UC24A2AN1 UC42C2CN1
UC24B3XN1
16 20.5
UC48C3XN1
19.5 23.5
UC24B2AN1 UC48C2CN1
UC30A3XN1
13 21
UC48D3XN1
23 23
UC30A2AN1 UC48D2CN1
UC30B3XN1
16 20.5
UC60C3XN1
19.5 25.5
UC30B2AN1 UC60C2CN1
UC36A3XN1
13 23.5
7/8
UC60D3XN1
23 25
UC36A2AN1 UC60D2CN1
UC36B3XN1
16 22.5
UC36B2AN1
(3X) = Models require field installed TXV. (3X) = Models require field installed TXV.
COIL - HC
B
19-1/2
25-1/2
A
21-1/2
A
C
20-1/4
21-1/2
INLET
OPENING
DIMENSIONS - HC Coils
Model
Dimensions — Inches Refrigerant Connections
ABC
Line Size
Liquid Vapor
HC18A**H1
15-5/16 13-1/4 14-3/16
3/8
3/4
HC30A**H1
7/8
HC36B**H1 17-9/16 15-1/2 16-7/16
HC42C**H1 21-5/16 19-1/4 20-3/16
HC60D**H1 25-5/16 23-1/4 24-3/16
