GENERAL
These completely assembled blower units are manufac-
tured under ISO 9002 Quality System Certification and
include a well-insulated cabinet, a DX cooling coil with
copper tubes and aluminum fins, an expansion valve, a
distributor, throwaway filters, a centrifugal blower, a
blower motor, a blower motor contactor, an adjustable
belt drive and a small holding charge of Refrigerant-22.
Blower motors and adjustable drives are factory-
installed on all units.
The units are shipped in the vertical position with a vertical air
discharge. Theblower sectioncan berepositioned asshown in
Figure1 for horizontal applications.
REFERENCE
Additional information for the accessories on this equip
-
ment is available in the following instructions:
•
Electric Heater - 550.13-N10.1V
•
Supply Air Plenum - 550.13-N10.2V
•
Return Air Grille - 550.13-N10.3V
•
Base - 550.13-N10.4V
•
Hot Water & Steam Coil - 550.13-N10.7V
Renewal Parts:
•
Refer to Parts Manual for complete listing of replacement
parts on this equipment.
All forms may be ordered from:
Publications Distribution Center
Unitary Products Group
P.O. Box 1592, York, PA 17405
INSPECTION
As soon as a unit is received, it should be inspected for
possible damage during transit. If damage is evident, the
extent of the damage should be noted on the carrier's de
-
livery receipt. A separate request for inspection by the
Installer should pay particular attention to the words: NOTE, CAU
-
TION and WARNING. Notes
are intended to clarify or make the in
-
stallation easier. Cautions
are given to prevent equipment damage. Warnings are given to alert installer that personal injury
MODELS K5EU090A50A & K4EU120A50A
(WORLD 50 HZ)
035-12122
®
INSTALLATION INSTRUCTION
SUNLINE™ SPLIT-SYSTEM
EVAPORATOR BLOWERS
(AIR COOLED)
Supersedes: Nothing 550.39-N4YI (894)
CAUTION
THE ENCLOSED INSTALLATION INSTRUCTIONS AND ANY APPLICABLE
LOCAL, STATE, AND NATIONAL CODES INCLUDING, BUT NOT LIMITED
TO, BUILDING, ELECTRICAL, AND MECHANICAL CODES.
THIS PRODUCT MUST BE INSTALLED IN STRICT COMPLIANCE WITH
WARNING
OPERATION OF THE PRODUCT COULD CAUSE PERSONAL INJURY
OR PROPERTY DAMAGE.
INCORRECT INSTALLATION MAY CREATE A CONDITION WHERE THE
