036-21023-005 Rev. A (0802)
Unitary Products Group 3
* Requires a 2FD Blower Time Delay unless a standard furnace is equipped with one.
**
Refer to Quick Selection Chart for specific furnace match-up.
ACCESSORIES*
Enhanced Coil Guard - An enhanced coil guard which offers
superior protection from hail and other types of damage is
available.
* For the most current accessory information, refer to the
price book or consult factory.
SOUND RATINGS*
*Rated in accordance with ARI Standard 270.
COOLING CAPACITY -With Air Handler Coils
UNIT
MODEL
VAR SPEED AIR HANDLER
COIL MODEL
COOLING
MODEL
ELEC. HEAT
KW
W
STAGE
(# CYL)
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
H4TS024 N+VSB12 5,7.5,10,15,18 17
G2FD024S17
1 600 12.4 10.0
14.8
13.5
2 820 24.0 16.8 12.0
G2FD030S17
1 600 12.8 10.2
15.4
14.0
2 820 24.6 17.2 12.5
G2FD036S17
1 600 13.0 10.4
15.5
14.3
2 820 25.0 17.5 12.5
H4TS030
N-VSB12 5,7.5,10,15,18 17
G2FD030S17
1 670 15.0 12.0
14.0
12.7
2 1035 30.0 21.6 11.0
G2FD036S17
1 670 15.4 12.2
14.5
13.1
2 1035 31.0 22.0 11.0
N-VSC16 5,7.5,10,15,20 21 G2FD042S21
1 690 16.4 13.4
15.3
14.1
2 1065 31.6 23.4 11.2
H4TS036 N-VSC16 5,7.5,10,15,20 21
G2FD036S21
1 770 20.0 16.0
15.0
13.7
2 1185 35.0 26.0 11.3
G2FD042S21
1 770 20.0 16.0
15.0
13.7
2 1185 35.0 26.0 11.3
G2FD048S21
1 770 20.6 16.6
16.0
14.4
2 1185 36.0 26.6 12.5
H4TS048
N-VSC16 5, 7.5,10,15,20 21 G2FD048S21
1 1050 25.0 20.0
15.2
14.1
2 1605 47.5 35.0 10.4
N-VSD20 5, 7.5,10,15,20 24
G2FD048S24
1 1050 25.0 20.0
15.3
14.2
2 1570 47.5 35.0 10.5
G2FD060S24
1 1050 25.0 21.0
15.5
14.0
2 1570 49.5 37.0 10.7
H4TS060 N-VSD20 5, 7.5,10,15,20 24
G2FD060S24
1 1250 33.0 26.4
14.5
13.5
2 1900 59.0 43.0 10.4
G2FD061H24
1 1250 33.0 26.4
15.0
14.0
2 1900 59.5 44.0 10.7
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
KW includes compressor, outdoor fan and indoor blower motor watts. Add-on coils include 365 watts/1000 CFM for blower motor.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
UNIT MODEL
SOUND RATINGS
DECIBELS
1 CYLINDER 2 CYLINDER
024 70 db 72 db
030 72 db 74 db
036 73 db 74 db
048 76 db 78 db
060 78 db 79 db
