036-21031-004 Rev. A (0603)
Unitary Products Group 19
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO E4FH30S06
EVAPORATOR COIL MODEL NO G2FD030(S,H)17
AIR TEMP.
ENTERING
OUTDOOR
UNIT
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
950 1050 1150
MBTUH K.W. C.O.P. MBTUH K.W. C.O.P. MBTUH K.W. C.O.P.
60
60 33.72.534.0233.92.514.0934.12.494.16
70 26.42.673.6633.12.663.7633.82.653.87
80 25.72.853.2932.32.843.4333.52.833.56
47
60 23.02.343.6229.22.333.6829.62.573.74
70 22.02.463.2628.02.463.3328.62.703.40
80 21.02.612.8926.82.622.9827.62.873.06
40
60 21.32.253.4126.82.383.4527.12.263.48
70 19.92.353.0625.22.503.1025.62.363.13
80 18.62.482.6923.62.652.7324.02.492.77
30
60 17.22.312.8122.82.332.8623.32.342.92
70 16.72.412.5521.62.432.5922.02.442.62
80 16.22.552.2720.12.562.2820.42.582.29
17
60 12.22.082.4317.62.102.4618.02.122.48
70 12.02.192.1616.42.212.1816.82.232.21
80 11.8 2.31 1.90 15.2 2.34 1.92 15.6 2.36 1.95
10
60 10.11.972.2515.12.002.2715.52.042.30
70 9.6 2.061.9313.62.091.9713.92.131.98
80 9.1 2.171.6312.22.191.6812.52.231.69
NOTE:
ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
F2RP/F2FP030 1.00 1.01 0.99
F2RP/F2FP036 1.00 1.01 0.99
G2FD035(S,H)14 1.00 1.01 0.99
G1HD036 1.00 1.01 0.99
G2FD036(S,H)17 1.00 1.01 0.99
G2FD036(S,H)21 0.99 1.00 0.99
G1UA036S14 1.00 1.01 0.99
G1FA036S14 1.00 1.01 0.99
G1UA036S17,21 1.00 1.01 0.99
G1FA036S17,21 1.00 1.01 0.99
