036-21031-004 Rev. A (0603)
Unitary Products Group 13
Multipliers for determining the performance with other indoor sections.
NOTE:
For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. E4FH036S06
INDOOR COIL MODEL NO. F2RP/F2FP036
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1150 1250 1350
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75
T.C. 40.5 37.4 34.3 31.6 40.8 37.7 34.7 31.9 41.0 37.9 35.0 32.1
S.C. 25.6 25.7 26.0 26.3 26.5 26.8 27.1 27.2 27.5 27.6 28.2 28.2
K.W 2.65 2.63 2.63 2.60 2.69 2.67 2.66 2.64 2.78 2.77 2.74 2.74
85
T.C. 38.8 35.8 32.8 30.2 39.1 36.1 33.2 30.5 39.3 36.3 33.5 30.8
S.C. 25.0 25.0 25.4 25.6 25.9 26.0 26.5 26.6 26.9 27.0 27.4 27.6
K.W 2.86 2.86 2.84 2.83 2.90 2.89 2.87 2.86 3.00 2.98 2.96 2.94
95
T.C. 37.2 34.3 31.6 28.9 37.5 34.6 31.9 29.2 37.6 34.9 32.1 29.6
S.C. 24.3 24.6 25.0 24.9 25.5 25.6 26.0 25.9 26.3 26.7 26.9 26.9
K.W 3.27 3.23 3.21 3.21 3.28 3.26 3.25 3.24 3.39 3.36 3.34 3.34
105
T.C. 35.5 32.7 30.1 27.6 35.7 33.0 30.3 27.9 35.9 33.2 30.5 28.2
S.C. 23.8 23.9 24.2 24.3 24.9 25.0 25.2 25.3 25.9 25.9 26.1 26.1
K.W 3.74 3.71 3.69 3.67 3.75 3.73 3.72 3.70 3.84 3.84 3.82 3.80
115
T.C. 33.8 31.1 28.6 26.3 34.0 31.4 28.9 26.6 34.2 31.6 29.0 27.1
S.C. 23.2 23.3 23.6 23.9 24.3 24.3 24.5 24.5 25.3 25.3 25.5 25.6
K.W 4.30 4.28 4.25 4.21 4.31 4.31 4.29 4.26 4.43 4.40 4.38 4.36
125
T.C. 32.1 29.5 27.1 25.0 32.3 29.8 27.5 25.3 32.5 30.0 27.5 26.0
S.C. 22.6 22.7 23.0 23.5 23.7 23.6 23.8 23.7 24.7 24.7 24.9 25.1
K.W 4.86 4.85 4.81 4.75 4.87 4.89 4.86 4.82 5.02 4.96 4.94 4.92
NOTE:
ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1AHB12 G2FD036(S,H)17 1.00 1.00 1.01
N1VSB12 G2FD036(S,H)17 1.01 1.01 0.96
F2RP042 1.00 1.00 1.01
G1UA048S21 1.02 1.02 1.02
G1UA048S17 1.01 1.01 1.01
G2FD42(S,H)21 1.01 1.01 1.01
G2FD046(S,H)17 1.01 1.01 1.01
G2FD036(S,H)21 1.00 1.00 1.01
G2FD036(S,H)17 1.00 1.00 1.01
G1FA048S21 1.02 1.02 1.02
G1FA048S17 1.01 1.01 1.01
